Elmo MO-1 - Output Video Selection Flow

28
・ When the USB power supply is enabled (when the AC adapter is not used) and
when the power is OFF (standby status), a video signal input to the [RGB IN]
terminal is output from the [RGB OUT] terminal. (EXT lamp is not lit.) The video
signal input to the [RGB IN] terminal is not output from the [RGB OUT] terminal
when the power is ON. (*1)
・ When the power is supplied from the USB port (the AC adapter is not used), a video
signal is not output from the HDMI OUT terminal and the RGB OUT terminal.(*2)
・ When the power is OFF (standby status), a video signal input to the HDMI IN
terminal is not output from the HDMI OUT terminal.
In the order that the output video changes (in the order that the LED lights up)
Connected
Item
①
Selection
Button
②
Selection
Button
③
Selection
Button
AC Adaptor
Power
ON
HDMI
→
RGB
→
EXT
→
To
①
USB Cable
Power
ON
USB
→
No
Change
AC Adaptor
USB Cable
Power
ON
HDMI
→
RGB
→
USB
EXT
→
To
①
N o t e
