20
Carry the product by holding the lower part of the body in both hands. Never hold
the product by the arm or the camera head.
Pay attention to prevent the camera head from knocking against a desk or the like.
Move the arm while supporting the body with your hand.
PREPARATION AND CONNECTION
Setting Up
N o t e
Lift up the other side of the arm.
Move the arm in the direction
indicated by an arrow.
Move the camera head so that
it is horizontal.
Hooking your finger to the
position indicated by an arrow
in the drawing, slightly lift up
the arm.
CAUTION
When moving the arm, pay attention not to pinch your finger.

Other manuals for Elmo MO-1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Elmo MO-1 and is the answer not in the manual?

Elmo MO-1 Specifications

General IconGeneral
Product colorPink
Built-in microphoneYes
Sensor typeCMOS
White balanceAuto, Manual
Optical sensor size1/3.2 \
Effective sensor resolution5 MP
Supported graphics resolutions-
Digital zoom8 x
Shooting area (WxD)257 x 342 mm
VGA (D-Sub) input ports1
AC input voltage100-240 V
Power supply typeAC
AC input frequency50 - 60 Hz
Cables includedAC, USB
Weight and Dimensions IconWeight and Dimensions
Depth226 mm
Width101 mm
Height338 mm
Weight550 g
Dimensions folded (WxDxH)101 x 226 x 28 mm
