Elmo MO-1 - Zoom and Brightness Controls; Video Output Status Indicators

14
Mark
Name
Function
⑧
Zoom In
To zoom in an object.
⑨
Zoom Out
To zoom out an object.
⑩
Bright
To brighten the camera image.
⑪
Dark
To darken the camera image.
⑫
Video Output
LED [HDMI]
When this LED is lit in blue, digital video is output.
Select the output mode with the Image Selection
button.
⑬
Video Output
LED [RGB]
When this LED is lit in blue, analog RGB video is
output.
Select the output mode with the Image Selection
button.
⑭
Video Output
LED [USB]
When this LED is lit in blue, the product can be
connected to a PC via a USB cable.
Select the output mode with the Image Selection
button.
⑮
Video Output
LED [EXT]
When this LED is lit in blue, external input video is
output.
Select the output mode with the Image Selection
button.
N o t e
The lamp is always OFF when power is turned on.
。
