56
Mechanical Adjustment
⁄6 The Y-motor !8 is separated from the base !9.
!8
!9
⁄7 Remove the setscrews @0 (2 pcs.).
@0
@0
⁄8 Remove the cord binder and disconnect the connector @2
from the printed circuit board S2
@1.
⁄9 Pry up the lock tab of the connector with a precision driver
and pull out the red
@3, orange @4, brown @5, white @6
and red
@7 cords.
Remove the Y-motor.
•AttachingY-motor
Follow the above procedure in reverse.
@1
@2
@3@4@5@6@7
