ELNA eXpressive920 - Removing Film Guides; Removing Y-Carriage

53
Mechanical Adjustment
•Removing Film guides
n Remove the setscrews r on the film guides.
r rr
r
r
t
t
m
Remove the setscrews t (2 pcs.) on the film guides.
t
t
•RemovingY-carriage
, Pull the cable in the direction of arrow y to disconnect
the flexible cable from the printed circuit board S2.
y
. Remove the setscrews u (2 pcs.).
u
