EMC Connectrix B Series User Manual

Installing the ED-DCX-4S-B in Equipment Cabinet
213
Port Side Exhaust Kit Installation Procedure
Note: For rails with round holes, use the clip nuts on the front rails for
securing 10-32 screws. For rails with square holes, use the retainer nuts
(H and I in Figure 44 on page 204). Also refer to Figure 49 on page 211.
6. Install the ED-DCX-4S-B door and required cable management
system. Refer to “RRP: Chassis door” on page 87 and “RRP:
Vertical cable management finger assemblies” on page 90.
