3410 Series Gas Ultrasonic Meters Operations Manual Section 6: Archive logs
3-9000-777 Rev E January 2018
Daily log 89
PrevDayMacro2*: Macro
bit 31
bit 30
bit 29
bit 28
bit 27
bit 26
bit 25
bit 24
bit 23
bit 22
bits 21-19
bit 18
bit 17
bit 16
bit 15-10
bit 9
bit 8
bit 7
bit 6
bit 5
bit 4
bit 3
bits 2-0
(unused)
IsMeasSndSpdRange
IsAvgSoundVelRangeErr
IsMeterVelAboveMaxLmt
IsHardFailedA
IsHardFailedB
IsHardFailedC
IsHardFailedD
(unused)
IsSNRTooLow
(unused)
IsPressureInvalid
IsTemperatureInvalid
IsAnyLogFull
(unused)
IsReverseFlowDetected
IsBoreBuildupDetected
IsLiquidDetected
IsAbnormalProfileDetected
IsReverseFlowDetected
IsSndVelCompErr
AreGasPropertiesInvalidInUse
(unused)
Paths A-B, Dual-path meters
Paths A-D, 4-path meters
SndVelA,
SndVelB,
SndVelC,
SndVelD
Flow-Gated
FlowVelA
FlowVelB
FlowVelC
FlowVelD
Flow-Gated
AvgFlow Flow-Gated
(Percent of good batch signals)
PctGoodA1, PctGoodA2
PctGoodB1, PctGoodB2,
PctGoodC1, PctGoodC2,
PctGoodD1, PctGoodD2
Average
QFlow Flow-Gated
QBase Flow-Gated
Table 6-1 Daily log content (Continued)
Data Point Log action
