Commissioning the Device in E2E iPro Parameter List • 65
RLP01 Polarity of Relay 1
Open/Close
RLP02 Polarity of Relay 2
RLP03 Polarity of Relay 3
RLP04 Polarity of Relay 4
RLP05 Polarity of Relay 5
RLP06 Polarity of Relay 6
RLP07 Polarity of Relay 7
RLP08 Polarity of Relay 8
RLP09 Polarity of Relay 9
RLP10 Polarity of Relay 10
RLP11 Polarity of Relay 11
RLP12 Polarity of Relay 12
RLP13 Polarity of Relay 13
RLP14 Polarity of Relay 14
RLP15 Polarity of Relay 15
RLd01 Delay of Relay 1
0-1200 Seconds
RLd02 Delay of Relay 2
RLd03 Delay of Relay 3
RLd04 Delay of Relay 4
RLd05 Delay of Relay 5
RLd06 Delay of Relay 6
RLd07 Delay of Relay 7
RLd08 Delay of Relay 8
RLd09 Delay of Relay 9
RLd10 Delay of Relay 10
RLd11 Delay of Relay 11
RLd12 Delay of Relay 12
RLd13 Delay of Relay 13
RLd14 Delay of Relay 14
RLd15 Delay of Relay 15
EEPR Parameters
EEPR_MinS EEPR - Minimum Steps 0-50 where 1=10 Steps
EEPR_MaxS EEPR - Maximum Steps 0-800 where 1=10 Steps
EEPR_PeakC EEPR - Peak Current (Bipolar only) 0-100 where 1=10 mA
EEPR_HoldC EEPR - Hold Current (Bipolar only) 0-100 where 1=10 mA
EEPR_StepR EEPR - Step Rate 10-600 Steps
EEPR_ExtraS EEPR - Extra Steps the valve is overdriven at each closure 1-500 Steps
EEPR_RelaxS EEPR - Relax Steps-The number of steps the valve is opened after
Extra steps
0-500 Steps
EEPR_PressF EEPR - Filter on the pressure 1-100 Seconds
EEPR_TempF EEPR - Filter on the temperature 1-100 Seconds
EEPR_InitS EEPR - Steps Init Regulation Minimum of 2, maximum adjusts based
on MaxS. 1=10 steps
Table 16-1 - iPro Parameter List
