Default Settings (continued)Table 7-1:
Item Choices Default
7. Simulate 0.00 to 22.00 mA 12.00 mA
Alarms
1. Logic high or low AL1 low, AL2, 3, 4, high
2. Assignments
a. AL1 and AL2 chlorine, temperature, fault, interval
timer
chlorine
b. AL3 and AL4 chlorine, temperature, fault, interval
timer
temperature
3. Deadband 0 to 9999 0
4. Interval timer settings
a. interval time 0.0 to 999.9 hr 24.0 hr
b. on time 0 to 999 sec 10 sec
c. recovery time 0 to 999 sec 60 sec
Measurement (chlorine)
a. units ppm or mg/L ppm
b. resolution 0.01 or 0.001 0.001
c. input filter 0 to 999 sec 5 sec
Temperature related settings
1. Units °C or °F °C
2. Temperature compensation automatic or manual automatic
Security code
1. Calibrate/Hold 000 to 999 000
2. Program/Display 000 to 999 000
Calibration - Analog Outputs
1. 4mA 0.000 to 22.000 mA 4.000 mA
2. 20 mA 0.000 to 22.000 mA 20.000 mA
Programming the transmitter
40 Rosemount TCL
