EMKO TRANS MINI AUTO - Canbus ECU; Baud Rate; J1939 ECU Type Selection

30
Note: =Parametersinthistableareonlyavailableat Trans-MiniAUTO.CAN
dis=disable
*
9
CANBUS ECU ( )Engine->CanBus ECU *
9
BaudRate:
0-20
1-50
2-100
3-125
4-250
5-500
6-800
7-1.000
Baud rate
J1939 ECU type
Device address
SPN version
Min
Default
UnitMax
0
7 4
13
0
0 255 17
1 3 1
kBaud
ECU remote control
Speed control enable
Oil pres cont. enab
Temp. control enable
ENABL
Device Address
0(dis)
SPNversion
ECURemoteControlviaJ1939
SpeedControlviaJ1939
OilPressureControlviaJ1939
Coolant TemperatureControlviaJ1939
Speed correction
50
SpeedCorrectionValue
%
0 100
Speed set point
1500
15001800/
SpeedSetPointSelection
RPM
Note: Changingabovementionedparameterbecomesonlyeffectiveafterrestartingtheunit.
ENABL/DISBL
ENABL/DISBL
ENABL/DISBL
ENABL/DISBL
ENABL
DISBL
DISBL
J1939ECU TypeSelection:
0-Disable
1-Standard
2-VolvoEMS1
3-VolvoEMS2
4-VolvoEMS2b
5-VolvoEDC3
6-VolvoEDC4
7-DeutzEMR2
8-DeutzEMR3
9-Perkins1300
10-Perkins ADEM3
11-Perkins ADEM4
12-ScaniaS6
13-ManMFR
BaudRate
J1939ECUTypeSelection
ItdefinestheusedBaudrate.
AllparticipantsontheCANbusmustusethesameBaudrate.
TheJ1939interfaceofthisunitcanbeoperatedwithdifferentECUs. Thisparameterdeterminesthe
operatingmodeoftheusedECUs.Ifthisparameterisselectedas“disable”,Nomessageswillbesent
orreceived.
VolvoEMS2enginetypes: TAD734, TAD940, TAD941, TAD1640, TAD1641, TAD1642.
VolvoEDC3enginetypes: TAD1240, TAD1241, TAD1242.
VolvoEDC4enginetypes: TD520, TAD520, TD720, TAD720, TAD721, TAD722.
Perkinsenginesfittedwiththe ADEM3/ ADEM4:2306,2506,1106,2806.
ScaniaS6enginetypes:DC9,DC12,DC16.
Note:
Note:
