EMKO TRANS MINI AUTO - Outputs

Min
Default
Unit
CONF. OUTPUT-1 ( )Outputs->Conf. output-1
Max
010
1220 43
Polarity
Function
0-NOT USED
1-AIRFLAP CONTROL
2-ALARMRESET
3-AUDIBLE ALARM
4-AUTOSTART INHIBIT
5-RESERVED
6-BATTERY HIGHVOLTAGE
7-BATTERY LOWVOLTAGE
8-RESERVED
9-CANECUPOWER(onlyavailableat Trans-MiniAUTO.CAN)
10-CANECUSTOP (onlyavailableat Trans-MiniAUTO.CAN)
11-CHARGE ALTERNATORFAILURE
12-COMMON ALARM
13-COMMONELECTRICAL TRIP ALARM
14-COMMONSHUTDOWN ALARM
15-COMMONWARNING ALARM
16-COOLINGFAN AFTERSTART
17-COOLINGFAN AFTERSTOP
18-COOLANT TEMPERATUREHIGHPRE-ALARM
19-COOLANT TEMPERATUREHIGHSHUTDOWN
20-COOLINGDOWN TIMERINPROGRESS
21-CRANKRELAY ENERGISED
22-DELAYED ALARMS ACTIVE
23-DIGITAL INPUT1 ALARM
24-DIGITAL INPUT2 ALARM
25-DIGITAL INPUT3 ALARM
26-RESERVED
27-RESERVED
28-RESERVED
29-RESERVED
30-RESERVED
31-RESERVED
32-RESERVED
33-RESERVED
34-RESERVED
35-RESERVED
36-RESERVED
37-RESERVED
38-RESERVED
39-EMERGENCY STOP
40-FAIL TOSTART ALARM
41-FAIL TOSTOP ALARM
42-CONFIGURABLE ANALOGINPUT CONTROL
43-FUEL RELAY ENERGISED
44-GASENGINEIGNITIONOUTPUT
45-GENERATOR AT REST
46-GENERATOR AVAILABLE
47-GENERATORCLOSED AUXILIARY
48-GENERATORFAILED TOCLOSE
49-GENERATORFAILED TOOPEN
50-GENERATORHIGHFREQUENCY PRE-ALARM
51-GENERATORHIGHFREQUENCY SHUTDOWN
52-GENERATORHIGHVOLTAGEPRE-ALARM
53-GENERATORHIGHVOLTAGESHUTDOWN
54-GENERATORLOADINHIBIT
55-GENERATORLOWFREQUENCY PRE-ALARM
56-GENERATORLOWFREQUENCY SHUTDOWN
57-GENERATORLOWVOLTAGEPRE-ALARM
58-GENERATORLOWVOLTAGESHUTDOWN
59-GENERATORSTOPPING
60-GENERATOROPENBREAKER
61-HORNOUTPUT LATCHED
62-HORNOUTPUT PULSED
63-LAMP TEST
64-RESERVED
65-LOSSOFMAGNETICPICK-UP SPEEDSIGNAL (onlyavailableat Trans-MiniAUTO.MPU)
66-LOW TEMPERATURE
67-MAINTENANCEDUE ALARM
68-GENERATORCLOSEBREAKER
69-RESERVED
70-RESERVED
71-RESERVED
72-RESERVED
73-RESERVED
74-RESERVED
75-RESERVED
76-RESERVED
77-RESERVED
78-NOLOADINGCOMMAND
79-OIL PRESSURELOWPRE-ALARM
80-OIL PRESSURELOWSHUTDOWN
83-OVERCURRENT PRE-ALARM
84-OVERCURRENT
85-OVERPOWERPRE-ALARM
86-OVERPOWERSHUTDOWN
87-OVERSPEEDPRE-ALARM
88-OVERSPEEDSHUTDOWN
89-PANEL LOCK
90-PRE-HEAT(duringpreheattimer)
91-PRE-HEAT(untilendofcranking)
92-PRE-HEAT(untilendofwarming)
93-PRE-HEAT(untilendsafetyon)
94-REMOTESTART PRESENT
95-REMOTESTOP DELAY INPROGRESS
96-SHORT CIRCUIT
97-SMOKELIMITING
98-STARTING ALARM
99-STARTING ALARMS ARMED
100-STOP RELAY ENERGISED
101-SYSTEMIN AUTOMODE
102-SYSTEMINMANUAL MODE
103-SYSTEMINSTOP MODE
104-SYSTEMIN TEST MODE
105-UNDERCURRENT PRE-ALARM
106-UNDERCURRENT
107-UNDERPOWERPRE-ALARM
108-UNDERPOWERSHUTDOWN
109-UNDERSPEEDPRE-ALARM
110-UNDERSPEEDSHUTDOWN
111-WAITINGFORGENERATOR
112-REVERSEPOWER
113-LOADSUPPLY FROMGENERATOR
114-RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
81-CONFIGURABLE ANALOGINPUT HIGHPREALARM
82-CONFIGURABLE ANALOGINPUT HIGHSHUTDOWN
115-CONFIGURABLE ANALOGINPUT LOWPRE-ALARM
116 CONFIGURABLE ANALOGINPUT LOWSHUTDOWN
117-
118-
119-
120-
121-CHOKE ACTIVE
122-REMOTECONTROL ACTIVE
-
0-NormallyOpen(Close To Activate)
1-NormallyClose(Open To Activate)
47
4.2.5Outputs
