EMKO TRANS MINI AUTO - Device Address; SPN Version; ECU Remote Control Via J1939; Oil Pressure Control Via J1939

31
SPNVersion
Thereare4differentSuspectParameterNumberversionswithJ1939protocol.Thedevicehasability
todetectingversion4automatically. Therefore,thisparameterisimportanttoshowalarmmessages
correctlyexceptversion4.
ECURemoteControlViaJ1939
Ifthisparameterisselectedas“Enable”, TheunitsendsremotecontrolmessagestotheECUifthe
selectedECUtypeissupportingtheJ1939RemotecontrolMessages. Availablemessagesareengine
start-stop,50/60HzselectionorIdlemode.ForsomeECUs;
Ifthisparameterisselectedas“Disable”, TheECUremotecontrolviatheJ1939protocolwillbe
disabled.
Ifthisparameterisselectedas“Enable”, ThespeedsensingfromJ1939ECUwillbeusedforthe
speed(Rpm)failures.
Ifthisparameterisselectedas“Enable”, TheoilpressuresensingfromJ1939ECUwillbeusedforthe
oilpressurefailuresandtheenginestartedsignal.
Ifthisparameterisselectedas“Enable”, ThecoolanttemperaturesensingfromJ1939ECUwillbe
usedforthecoolanttemperaturefailures.
Thisparameterusedfortoselecttherequestedenginespeedas1500Rpm(50Hz)or1800Rpm
(60Hz). Thescenario;firstchangetheparameter,nextwaitatleast5seconds,andthenstart
theengine.
Thisparametercanbechangedbetween0and100%. Theengineshouldchangethespeedas
follows:
0%=ratedspeed–speeddeviationECUe.g.1500–120=1380rpm
50%=ratedspeede.g.=1500rpm
100%=ratedspeed+speeddeviationECUe.g.1500+120=1620rpm
(50/60Hz)
Note:
SpeedControlviaJ1939
OilPressureControlviaJ1939
CoolantTemperatureControlviaJ1939
SpeedSetPointSelection
SpeedCorrectionValue
VolvoEMS1,
VolvoEMS2,
VolvoEMS2b,
VolvoEDC3
VolvoEDC4,
DeutzEMR2,
DeutzEMR3
Perkins1300,
Perkins ADEM3,
Perkins ADEM4
17
3 43
ECU
TheunitsendsJ1939requestandcontrolmessageswiththisID.ItmustbechangedfordifferentECU
typesaccordingtothefollowingtable. TheECUlistensonlytocontrolmessages,iftheyaresenttothe
correctaddress.
Device Address
VolvoEMS1,
VolvoEMS2,
VolvoEMS2b,
VolvoEDC3
Parameter
VolvoEDC4,
DeutzEMR2,
DeutzEMR3
Perkins1300,
Perkins ADEM3,
Perkins ADEM4
Standard
Yes
Yes
Yes
Yes
No
No
No
No
No
No
No
No
No
No
No
No
RemoteStart
RemoteStop
50/60Hz
Selection
IdleMode
ScaniaS6
Yes
Yes
Yes
Yes
ScaniaS6
39
