EMKO TRANS MINI AUTO - Start;Stop Diagram for Gasoline Engine

37
Start/StopDiagramfor GASOLINEENGINE
Startrequest
Pre-heat Starter Fuelrelay Choke Engine
monitoringON
Ratedspeed
[RPM]
t[s]
Starting
Unsuccessful
Successful
Stopping
t
PH
2s
[1/min ];RPM
t[s] t[s] t[s] t[s] t[s]
t
R
t
CR
t
CR
t
D
Crankdisconnect
magneticpick-upspeed
t
CH
t
CH
t
t
t
t
t
PH
CR
R
D
CH
Preheatingtime [s]
Engagementtime [s]
Intervalbetween2startattempts [s]
Enginedelayedmonitoring [s]
Choketime [s]
