Emotron FDU Series User Manual

16 Mounting CG Drives & Automation 01-7491-01r0
Fig. 8 Emotron FDU Model 48/52-026 to 046 (Frame size
C).
Fig. 9 Cable interface for mains, motor and communication,
Emotron FDU Model 48/52-026 to 046 (Frame size
C).
Fig. 10 Emotron FDU Model 48-025 to
48-058 (Frame size C2), Model 69-002 to 69-025
(Frame size C2(69)), backside view.
Fig. 11 Bottom view Emotron FDU Model 48-025 to 48-058
(Frame size C2) Model 69-002 to 69-025 (Frame size
C2(69)), with cable interface for mains, motor, DC+/
DC-, brake resistor and control.
24 kg
(53 lb)
C
D
F
G
ø13 mm(x2)
E
B
A
ø7 mm(x4)
(0.27 in)
(0.51 in)
Gland
M25 (026-031)
Glands
M20
Glands
M32 (026-031)
M32 (037-046)
M40 (037-046)
IP21 top cover (optional)
ø7mm (x4)
(0.27 in)
ø13 mm(x2)
(0.51 in)
G
A
K
F
17 kg
(38 lb)
B
H
I
C
J
E
D
PE
L1 L2 L3 DC- DC+ R U V W
Table 7 Dimensions connected to fig. 8 and fig. 10.
Frame
size
Emotron
FDU
model
Dimensions in mm (in)
A B C D E F
G
(depth)
H I J K
C 026 - 046
512
(20.2)
492
(19.4)
128.5
(5.04)
24.8
(0.95)
10
(0.39)
178
(7)
292
(11.5)
----
C2 025 - 058
585.5
(23)
471
(18.5)
128.5
(5.04)
23.8
(0.91)
13
(0.51)
167
(7)
267 (10.5)
IP21 282
(11.1)
196
(7.7)
10
(0.39)
23.5
(0.9)
496
(19.5)
C2(69) 002 - 025
