Emotron FDU Series User Manual

CG Drives & Automation 01-7491-01r0 Menu List 233
334 Dec MotPot 16s 43104 169/8 4C20 19488 Long, 1=0.01s EInt
335 Acc<Min Spd 10s 43105 169/9 4C21 19489 Long, 1=0.01s EInt
336 Dec<Min Spd 10s 43106 169/10 4C22 19490 Long, 1=0.01s EInt
337 Acc Rmp Linear 43107 169/11 4C23 19491 UInt UInt
338 Dec Rmp Linear 43108 169/12 4C24 19492 UInt UInt
339 Start Mode Fast 43109 169/13 4C25 19493 UInt UInt
33A Spinstart Off 43110 169/14 4C26 19494 UInt UInt
33B Stop Mode Decel 43111 169/15 4C27 19495 UInt UInt
33C Brk Release 0s 43112 169/16 4C28 19496 Long, 1=0.01s EInt
33D Release Spd 0rpm 43113 169/17 4C29 19497 Int, 1=1rpm Int
33E Brk Engage 0s 43114 169/18 4C2A 19498 Long, 1=0.01s EInt
33F Brk Wait 0s 43115 169/19 4C2B 19499 Long, 1=0.01s EInt
33G Vector Brake Off 43116 169/20 4C2C 19500 UInt UInt
33H Brk Fault 1s 43117 169/21 4C2D 19501 Long, 1=0.01s EInt
33I Release Trq 0% 43118 169/22 4C2E 19502 Long, 1=1% EInt
33K Start Vector Normal (U) 43119 169/23 4C2F 19503 UInt UInt
340 Speed [340]
341 Min Speed 0rpm 43121 169/25 4C31 19505 Int, 1=1rpm Int
342 Stp<MinSpd Off 43122 169/26 4C32 19506 Long, 1=0.01s EInt
343 Max Speed Sync speed 43123 169/27 4C33 19507 Int, 1=1rpm Int
344 SkipSpd 1 Lo 0rpm 43124 169/28 4C34 19508 Int, 1=1rpm Int
345 SkipSpd 1 Hi 0rpm 43125 169/29 4C35 19509 Int, 1=1rpm Int
346 SkipSpd 2 Lo 0rpm 43126 169/30 4C36 19510 Int, 1=1rpm Int
347 SkipSpd 2 Hi 0rpm 43127 169/31 4C37 19511 Int, 1=1rpm Int
348 Jog Speed 50rpm 43128 169/32 4C38 19512 Int, 1=1rpm Int
349 Droop Speed 0% 43120 169/24 4C30 19504
Long,
1=0.01%
EInt
350 Torques [350]
351 Max Torque 120% 43141 169/45 4C45 19525 Long, 1=1% EInt
352 IxR Comp Off 43142 169/46 4C46 19526 UInt UInt
353 IxR CompUsr 0% 43143 169/47 4C47 19527 Long, 1=0.1% EInt
354 Flux optim Off 43144 169/48 4C48 19528 UInt UInt
355 Max Power Off 43145 169/49 4C49 19529 Long, 1=1% EInt
360
Preset
References
[360]
361 Motor Pot Non volatile 43131 169/35 4C3B 19515 UInt UInt
362 Preset Ref 1 0 43132 169/36 4C3C 19516 Long, 1=0.001 EInt
363 Preset Ref 2 250 43133 169/37 4C3D 19517 Long, 1=0.001 EInt
364 Preset Ref 3 500 43134 169/38 4C3E 19518 Long, 1=0.001 EInt
365 Preset Ref 4 750 43135 169/39 4C3F 19519 Long, 1=0.001 EInt
Menu Parameters
Default
settings
Modbus
Instance/
Device Net
No.
Profibus
slot/index
EtherCAT
index
(HEX)
Profinet
index
Fieldbus
format
Modbus
format
Notes
