Emotron FDU Series User Manual

234 Menu List CG Drives & Automation 01-7491-01r0
366 Preset Ref 5 1000 43136 169/40 4C40 19520 Long, 1=0.001 EInt
367 Preset Ref 6 1250 43137 169/41 4C41 19521 Long, 1=0.001 EInt
368 Preset Ref 7 1500 43138 169/42 4C42 19522 Long, 1=0.001 EInt
369
Key Ref Mode MotPot 43139 169/43 4C43 19523 UInt UInt
380
PID Process
Control [380]
381 PID Control Off 43154 169/58 4C52 19538 UInt UInt
383 PID P Gain 1 43156 169/60 4C54 19540 Long, 1=0.1 EInt
384 PID I Time 1s 43157 169/61 4C55 19541 Long, 1=0.01s EInt
385 PID D Time 0s 43158 169/62 4C56 19542 Long, 1=0.01s EInt
386 PID<MinSpd Off 43371 170/20 4D2B 19755 Long, 1=0.01s EInt
387 PID Act Marg 0 43372 170/21 4D2C 19756 Long, 1=0.001 EInt
388 PID Stdy Tst Off 43373 170/22 4D2D 19757 Long, 1=0.01s EInt
389 PID Stdy Mar 0 43374 170/23 4D2E 19758 Long, 1=0.001 EInt
390
Pump/Fan
Control [390]
391 Pump enable Off 43161 169/65 4C59 19545 UInt UInt
392 No of Drives 2 43162 169/66 4C5A 19546 UInt, 1=1 UInt
393 Select Drive Sequence 43163 169/67 4C5B 19547 UInt UInt
394 Change Cond Both 43164 169/68 4C5C 19548 UInt UInt
395 Change Timer 50h 43165 169/69 4C5D 19549 UInt, 1=1h UInt
396 Drives on Ch 0 43166 169/70 4C5E 19550 UInt, 1=1 UInt
397 Upper Band 10% 43167 169/71 4C5F 19551 Long, 1=1% EInt
398 Lower Band 10% 43168 169/72 4C60 19552 Long, 1=1% EInt
399 Start Delay 0s 43169 169/73 4C61 19553 Long, 1=1s EInt
39A Stop Delay 0s 43170 169/74 4C62 19554 Long, 1=1s EInt
39B Upp Band Lim 0% 43171 169/75 4C63 19555 Long, 1=1% EInt
39C Low Band Lim 0% 43172 169/76 4C64 19556 Long, 1=1% EInt
39D Settle Start 0s 43173 169/77 4C65 19557 Long, 1=1s EInt
39E TransS Start 60% 43174 169/78 4C66 19558 Long, 1=1% EInt
39F Settle Stop 0s 43175 169/79 4C67 19559 Long, 1=1s EInt
39G TransS Stop 60% 43176 169/80 4C68 19560 Long, 1=1% EInt
39H Run Time 1
31051 121/195 241B 1051 Long, 1=1h EInt
31052 121/196 241C 1052 Long, 1=1m EInt
31053 121/197 241D 1053 Long, 1=1s EInt
39H1 Rst Run Tm1 No 38 0/37 2026 38 UInt UInt
39I Run Time 2
31054 121/198 241E 1054 Long, 1=1h EInt
31055 121/199 241F 1055 Long, 1=1m EInt
31056 121/200 2420 1056 Long, 1=1s EInt
39I1 Rst Run Tm2 39 0/38 2027 39 UInt UInt
Menu Parameters
Default
settings
Modbus
Instance/
Device Net
No.
Profibus
slot/index
EtherCAT
index
(HEX)
Profinet
index
Fieldbus
format
Modbus
format
Notes
