Emotron FDU Series User Manual

CG Drives & Automation 01-7491-01r0 Menu List 237
5133 AnIn1 Bipol 20mA 43205 169/109 4C85 19589 Long, 1=0.01 EInt
5134 AnIn1 FcMin Min 43206 169/110 4C86 19590 UInt UInt
5135 AnIn1 VaMin 0 43541 170/190 4DD5 19925 Long, 1=0.001 EInt
5136 AnIn1 FcMax Max 43207 169/111 4C87 19591 UInt UInt
5137 AnIn1 VaMax 0 43551 170/200 4DDF 19935 Long, 1=0.001 EInt
5138 AnIn1 Oper Add + 43208 169/112 4C88 19592 UInt UInt
5139 AnIn1 Filt 0.1s 43209 169/113 4C89 19593
Long,
1=0.001s
EInt
513A AnIn1 Enabl On 43210 169/114 4C8A 19594 UInt UInt
514 AnIn2 Fc Off 43211 169/115 4C8B 19595 UInt UInt
515 AnIn2 Setup 4-20mA 43212 169/116 4C8C 19596 UInt UInt
516 AnIn2 Advan
5161 AnIn2 Min 4mA 43213 169/117 4C8D 19597 Long, 1=0.01 EInt
5162 AnIn2 Max 20mA 43214 169/118 4C8E 19598 Long, 1=0.01 EInt
5163 AnIn2 Bipol 20mA 43215 169/119 4C8F 19599 Long, 1=0.01 EInt
5164 AnIn2 FcMin Min 43216 169/120 4C90 19600 UInt UInt
5165 AnIn2 VaMin 0 43542 170/191 4DD6 19926 Long, 1=0.001 EInt
5166 AnIn2 FcMax Max 43217 169/121 4C91 19601 UInt UInt
5167 AnIn2 VaMax 0 43552 170/201 4DE0 19936 Long, 1=0.001 EInt
5168 AnIn2 Oper Add + 43218 169/122 4C92 19602 UInt UInt
5169 AnIn2 Filt 0,1s 43219 169/123 4C93 19603
Long,
1=0.001s
EInt
516A AnIn2 Enabl On 43220 169/124 4C94 19604 UInt UInt
517 AnIn3 Fc Off 43221 169/125 4C95 19605 UInt UInt
518 AnIn3 Setup 4-20mA 43222 169/126 4C96 19606 UInt UInt
519 AnIn3 Advan
5191 AnIn3 Min 4mA 43223 169/127 4C97 19607 Long, 1=0.01 EInt
5192 AnIn3 Max 20mA 43224 169/128 4C98 19608 Long, 1=0.01 EInt
5193 AnIn3 Bipol 20mA 43225 169/129 4C99 19609 Long, 1=0.01 EInt
5194 AnIn3 FcMin Min 43226 169/130 4C9A 19610 UInt UInt
5195 AnIn3 VaMin 0 43543 170/192 4DD7 19927 Long, 1=0.001 EInt
5196 AnIn3 FcMax Max 43227 169/131 4C9B 19611 UInt UInt
5197 AnIn3 VaMax 0 43553 170/202 4DE1 19937 Long, 1=0.001 EInt
5198 AnIn3 Oper Add + 43228 169/132 4C9C 19612 UInt UInt
5199 AnIn3 Filt 0,1s 43229 169/133 4C9D 19613
Long,
1=0.001s
EInt
519A AnIn3 Enabl On 43230 169/134 4C9E 19614 UInt UInt
51A AnIn4 Fc Off 43231 169/135 4C9F 19615 UInt UInt
51B AnIn4 Setup 4-20mA 43232 169/136 4CA0 19616 UInt UInt
51C AnIn4 Advan
51C1 AnIn4 Min 4mA 43233 169/137 4CA1 19617 Long, 1=0.01 EInt
Menu Parameters
Default
settings
Modbus
Instance/
Device Net
No.
Profibus
slot/index
EtherCAT
index
(HEX)
Profinet
index
Fieldbus
format
Modbus
format
Notes
