Emotron FDU Series User Manual

238 Menu List CG Drives & Automation 01-7491-01r0
51C2 AnIn4 Max 20mA 43234 169/138 4CA2 19618 Long, 1=0.01 EInt
51C3 AnIn4 Bipol 20mA 43235 169/139 4CA3 19619 Long, 1=0.01 EInt
51C4 AnIn4 FcMin Min 43236 169/140 4CA4 19620 UInt UInt
51C5 AnIn4 VaMin 0 43544 170/193 4DD8 19928 Long, 1=0.001 EInt
51C6 AnIn4 FcMax Max 43237 169/141 4CA5 19621 UInt UInt
51C7 AnIn4 VaMax 0 43554 170/203 4DE2 19938 Long, 1=0.001 EInt
51C8 AnIn4 Oper Add + 43238 169/142 4CA6 19622 UInt UInt
51C9 AnIn4 Filt 0,1s 43239 169/143 4CA7 19623
Long,
1=0.001s
EInt
51CA AnIn4 Enabl On 43240 169/144 4CA8 19624 UInt UInt
520
Digital Inputs
[520]
521 DigIn 1 RunL 43241 169/145 4CA9 19625 UInt UInt
522 DigIn 2 RunR 43242 169/146 4CAA 19626 UInt UInt
523 DigIn 3 Off 43243 169/147 4CAB 19627 UInt UInt
524 DigIn 4 Off 43244 169/148 4CAC 19628 UInt UInt
525 DigIn 5 Off 43245 169/149 4CAD 19629 UInt UInt
526 DigIn 6 Off 43246 169/150 4CAE 19630 UInt UInt
527 DigIn 7 Off 43247 169/151 4CAF 19631 UInt UInt
528 DigIn 8 Reset 43248 169/152 4CB0 19632 UInt UInt
529 B1 DigIn 1 Off 43501 170/150 4DAD 19885 UInt UInt
52A B1 DigIn 2 Off 43502 170/151 4DAE 19886 UInt UInt
52B B1 DigIn 3 Off 43503 170/152 4DAF 19887 UInt UInt
52C B2 DigIn 1 Off 43504 170/153 4DB0 19888 UInt UInt
52D B2 DigIn 2 Off 43505 170/154 4DB1 19889 UInt UInt
52E B2 DigIn 3 Off 43506 170/155 4DB2 19890 UInt UInt
52F B3 DigIn 1 Off 43507 170/156 4DB3 19891 UInt UInt
52G B3 DigIn 2 Off 43508 170/157 4DB4 19892 UInt UInt
52H B3 DigIn 3 Off 43509 170/158 4DB5 19893 UInt UInt
530
Analogue
Outputs [530]
531 AnOut1 Fc Speed 43251 169/155 4CB3 19635 UInt UInt
532 AnOut1 Setup 4-20mA 43252 169/156 4CB4 19636 UInt UInt
533
AnOut 1 Advan
5331 AnOut 1 Min 4mA 43253 169/157 4CB5 19637 Long, 1=0.01 EInt
5332 AnOut 1 Max 20mA 43254 169/158 4CB6 19638 Long, 1=0.01 EInt
5333 AnOut1Bipol 20mA 43255 169/159 4CB7 19639 Long, 1=0.01 EInt
5334 AnOut1FCMin Min 43256 169/160 4CB8 19640 UInt UInt
5335 AnOut1VaMin 0 43545 170/194 4DD9 19929 Long, 1=0.001 EInt
5336
AnOut1FCMax Max 43257 169/161 4CB9 19641 UInt UInt
5337
AnOut1VaMax 0 43555 170/204 4DE3 19939 Long, 1=0.001 EInt
Menu Parameters
Default
settings
Modbus
Instance/
Device Net
No.
Profibus
slot/index
EtherCAT
index
(HEX)
Profinet
index
Fieldbus
format
Modbus
format
Notes
