Emotron FDU Series User Manual

CG Drives & Automation 01-7491-01r0 Mounting 21
Fig. 25 Emotron FDU Model 48-365-54 (Frame size FA).
Fig. 26 Cable interface for mains, motor, DC+/DC-, brake
resistor and communication, Emotron FDU Model
48-365-54 (Frame size FA).
Fig. 27 Side view Emotron FDU Model 48-365-54 (Frame
size FA).
C
H
B
F
G
A
E
D
ø16 mm(x3)
(0.63 in)
ø9 mm(x6)
(0.35 in)
95 kg
(209 lb)
Cable glands M20
(x5)
(0.91 - 2.1 in)
Ø23-55 /M63
Cable flexible leadthrough
Table 12 Dimensions IP54 connected to fig. 25.
Frame
size
Emotron FDU
model
Dimension in mm (in)
A B C D E F
G
(depth)
H
FA 365
1055
(41.5)
1395
(54.9
300
(11.8)
38
(1.5)
32
(1,26)
345
(13.6)
365
(14.4)
157
(6.18)
