PlasmaQuant MS product family Specification

135

Max. Water Pressure 500 kPa (72,5 psi)

Pressure at the instrument water inlet

Water Purity Conductivity: permitted range 75-150 µS/cm, target range 100-

120 µS/cm (particle size < 0.1 mm)

pH: Between 7-9

Total Chlorine: < 20 mg/L (20 ppm), total Nitrate: < 10 mg/L

(10 ppm), total Sulfate: < 100 mg/L (100 ppm)

15.1.4 Autosampler ASPQ 3300 data

Dimensions W x H x D 285 mm x 510 mm x 490 mm

Mass 15 kg

Supply voltage

Frequency

100-240 V AC

50/60 Hz

Fuse 5 A

Typical average power consumption 75 VA

Racks

Sample cups

3 for sample cups

2 for special cups (standards and QC solutions)

Wash bottle 2 L

15.1.5 Autosampler Cetac ASX-560

Dimensions W x H x D 580 mm x 620 mm x 550 mm

Mass 12 kg

Supply voltage

Frequency

100-240 V AC

47-63 Hz
