Endress+Hauser Deltabar M PMD55 User Manual

Installation Cerabar M, Deltabar M, Deltapilot M / 4...20 mA HART
24 Endress+Hauser
Typical installation arrangements
P01-PMD55xxx-17-xx-xx-xx-001
A: Installation for horizontal impulse pipes; H2 version
B: Installation for vertical impulse pipes; V1 version
1: Deltabar M; 2: Adapter; 3: Mounting bracket
A
B
1
2
3
1
2
3
PMD55, H2
PMD55,V1
