Endress+Hauser Deltapilot S DB50 User Manual

Deltapilot S
12 Endress+Hauser
FieldCare –
HART, PROFIBUS PA
FieldCare is an Endress+Hauser asset management tool based on FDT technology. With FieldCare, you can
configure all Endress+Hauser devices as well as devices from other manufacturers that support the FDT
standard. The following operating systems are supported: WinNT4.0, Win2000 and Windows XP.
FieldCare supports the following functions:
• Configuration of transmitters in offline and online operation
• Loading and saving device data (upload/download)
• Documentation of the measuring point
Commuwin II –
HART, PROFIBUS PA
Commuwin II is a graphically supported operating program for intelligent measuring devices with the
communication protocols HART and PROFIBUS PA. The following operating systems are supported:
Win 3.1/3.11, Win 95, Win 98, WinNT4.0 and Win2000.
Commuwin II supports the following functions:
• Configuration of measuring devices in online operation via matrix operation
• Loading and saving device data (upload/download)
• Visualization of measured values and limit values
• Presentation and recording of measured values with a line recorder.
Connection option:
• HART via Commubox FXA191 with the serial interface RS 232 C of a computer or via Commubox FXA195
with the USB interface of a computer
• PROFIBUS PA via segment coupler and PROFIBUS interface card
Remote operation –
FOUNDATION Fieldbus
An FF configuration program is required to integrate a device with "FOUNDATION Fieldbus signal" into an FF
network or to set the FF-specific parameters. Please contact your local Endress+Hauser Sales Center for more
information.
Input (measured variable)
Measured variable Hydrostatic pressure
Measuring range
Measuring range Measuring limit Recommended
span
Overload Vacuum resistance Version in the
order code
1
lower (LRL) upper (URL) min./max.
[bar] [bar] [bar] bar
abs
bar
0 to +100 mbar 0 +0.1 0.025/0.1 8 –0.1 BA
0 to +400 mbar 0 +0.4 0.04/0.4 8 –0.4 BB
0 to +1200 mbar 0 +1.2 0.12/1.2 24 –0.9 BC
0 to +4 bar 0 +4 0.4/4 24 –0.9 BD
0 to +10 bar 0 +10 1/10 40 –0.9 BE
–100 to +100 mbar –0.1 +0.1 0.025/0.1 8 –0.1 DA
–400 to +400 mbar –0.4 +0.4 0.04/0.4 8 –0.4 DB
–900 to +1200 mbar –0.9 +1.2 0.12/1.2 24 –0.9 DC
–900 to +4000 mbar –0.9 +4 0.4/4 24 –0.9 DD
–0.9 to +10 bar –0.9 +10 1/10 40 –0.9 DE
1) See also Page 36 ff, "Ordering information" chapter, feature 40 "Measuring range"
