Endress+Hauser Deltapilot S DB50 - DB50 A - Compact Version

Deltapilot S
46 Endress+Hauser
DB50A – compact version
→For continuation of ordering information for DB50A, see the following page.
10 Approval:
A Version for non-hazardous area
N ATEX II 3 G EEx nA II T6
O FM IS, Class I, Division 1, 2, Groups A – D
S CSA IS, Class I, Division 1, Groups A – D
T CSA IS, Class I, Division 2, Groups A – D
20 Probe:
C Compact version
30 Process connection:
Threaded connection
12 ANSI 1 1/2 NPT, AISI 316L
ANSI flanges
30 1 1/2" 150 Ibs RF, AISI 316/316L
31 2" 150 lbs RF, AISI 316/316L
32 3" 150 Ibs RF, AISI 316/316L
33 4" 150 lbs RF, AISI 316/316L
JIS flange
7C JIS 10 K 50 A RF, AISI 316L
40 Measuring range:
FA 0 to 1.5 psi/1 mH
2
O/40 inH
2
O
FB 0 to 6 psi/4 mH
2
O/160 inH
2
O
FC 0 to 15 psi/12 mH
2
O/480 inH
2
O
FD 0 to 60 psi/40 mH
2
O/1600 inH
2
O
FE 0 to 150 psi/100 mH
2
O/4000 inH
2
O
GA –1.5 to 1.5 psi/1 mH
2
O/40 inH
2
O
GB –6 to 6 psi/4 mH
2
O/160 inH
2
O
GC –13 to 15 psi/12 mH
2
O/480 inH
2
O
GD –13 to 60 psi/40 mH
2
O/1600 inH
2
O
GE –13 to 150 psi/100 mH
2
O/4000 inH
2
O
50 Linearity; Fill fluid:
1 < 0.2 % of measuring range; FDA compliant
2 < 0.2 % of measuring range; inert oil
3 < 0.1 % of measuring range; FDA compliant
4 < 0.1 % of measuring range; inert oil
Z See additional specification
60 Measuring sensor seal:
1Viton
2EPDM
5Kalrez
3 Sensor welded
70 Electronics; Output:
Electronic inserts without integrated overvoltage protection
A Without integrated electronic insert (e.g. for ordering spare parts)
B FEB11, 3-wire analog signal
C FEB17, 2-wire PFM signal
E FEB22, 4 to 20 mA, HART
G FEB22, 4 to 20 mA, HART, with FHB20 onsite display
H FEB24, PROFIBUS PA
K FEB24, PROFIBUS PA, with FHB20 onsite display
1 FEB26, FOUNDATION Fieldbus
2 FEB26, FOUNDATION Fieldbus, with FHB20 onsite display
Electronic inserts with integrated overvoltage protection
M FEB11P, 3-wire analog signal
N FEB17P, 2-wire PFM signal
R FEB22P, 4 to 20 mA, HART
T FEB22P, 4 to 20 mA, HART, with FHB20 onsite display
U FEB24P, PROFIBUS PA
W FEB24P, PROFIBUS PA, with FHB20 onsite display
DB50A Order code
