Deltapilot S
Endress+Hauser 59
Documentation
Field of Activities • Pressure measurement, powerful measuring devices for process pressure, differential pressure, level and
flow: FA004P/00/en
Technical Information on
switching unit
• Level measurement, silometer FMC4120: TI077F/00/en
• Level measurement, Prolevel FMB662: TI234F/00/en
Operating Instructions • Deltapilot S HART: BA152P/00/en
• Deltapilot S PROFIBUS PA: BA164F/00/en
• Deltapilot S FOUNDATION Fieldbus: BA232F/00/en
• PROFIBUS DP/PA, Guidelines for planning and commissioning: BA034S/04/en
• FOUNDATION Fieldbus Overview, Installation and Commissioning Guidelines: BA013S/04/en
Safety Instructions
Installation Drawings/
Control Drawings
Overfill protection • WHG: ZE217F/00/en: HART
• WHG: ZE238F/00/en: PROFIBUS PA
Certificate/explosion
protection
Device Electronics Documentation
ATEX II 1/2 G EEx ia IIC T6 DB50, DB50L,
DB51, DB52
–PFM
–4 to 20 mA HART
– PROFIBUS PA
– FOUNDATION
Fieldbus
– XA002F
– XA002F
– XA007F
– XA135F
ATEX II 2 G EEx ia IIC T6 DB53 – PFM
–4 to 20 mA HART
– PROFIBUS PA
– FOUNDATION
Fieldbus
– XA002F
– XA002F
– XA007F
– XA135F
ATEX 1/2 G EEx nA II T6 DB50, DB50L,
DB51, DB52,
DB53
–PFM
–4 to 20 mA HART
– PROFIBUS PA
– FOUNDATION
Fieldbus
– XA189F
– XA189F
– XA189F
– XA189F
ATEX II 1/2 G EEx ia IIB T6 DB52 – PFM
–4 to 20 mA HART
– PROFIBUS PA
– FOUNDATION
Fieldbus
– XA002F
– XA002F
– XA007F
– XA135F
Certificate/explosion
protection
Device Electronics Documentation
CSA IS Class I, Division 1,
Groups A-D
DB50(A),
DB50L, DB50S,
DB51(A), DB 52(A),
DB53(A)
–PFM
–4 to 20 mA HART
– PROFIBUS PA
– FOUNDATION
Fieldbus
– Order number: 016586-0000
– Order number: 960351-1034
– ZD036F + ZD021F
– ZD068F + ZD021F
FM IS Class I, Division 1, 2
Groups A-D
DB50A, DB50S,
DB51A, DB52A,
DB53A
–PFM
–4 to 20 mA HART
– PROFIBUS PA
– FOUNDATION
Fieldbus
– Order number: 017054-0000
– Order number: 017054-0000
– ZD024F + ZD021F
– ZD067F + ZD021F
