Deltapilot S
56 Endress+Hauser
Accessories
Display and operating module
FHB20
The FHB20 display and operating module is available for onsite operation for the following electronic inserts.
• HART – FEB22(P)
• PROFIBUS PA – FEB24(P)
• FOUNDATION Fieldbus – FEB26
• Material: POM (polyoxymethylene)
• Order number: 942512-0100
Note!
• The display and operating module only fits under a cover with a sight glass (high cover), see this chapter,
"Cover with sight glass" section. If you order the FHB20 onsite display by means of the order structure, the
Deltapilot S with a high cover is delivered (→ see Page 37, "Ordering information" chapter, feature 70
"Electronic insert").
• Once you have configured a device with the FHB20 display and operating module, you can remove the
display and use it to configure other devices. Only remove the display from an electronic insert, or attach it
to an electronic insert, in a deenergized state.
• → See also Page 10, "Human interface" chapter.
Cover with sight glass (high
cover)
Cover with sight glass depending on the housing version:
Housing adapter with
mounting bracket for humid,
damp and difficult-to-access
mounting locations
With the housing adapter and mounting bracket, you have the option of mounting the housing with the
electronic insert away from the measuring point. The allows problem-free measurement
• under particularly difficult measuring conditions (in confined or difficult-to-access mounting locations)
• in the event of extreme fluctuations in temperature at the tank wall
IP 68 protection applies for the housing adapter. The mounting bracket is suitable for pipe and wall mounting.
→ See also page 19, "Housing adapter with mounting bracket" section and Page 31, "Dimensions" section.
Mounting bracket Mounting bracket for pipe and wall mounting:
• Material: AISI 304 (1.4301)
• Order number: 919806-1000
→ See also Page 19, "Housing adapter with mounting bracket" section and Page 30, "Dimensions of
Deltapilot S DB53 and DB53 (A) "Suspension clamp and mounting bracket" section.
Extension cable shortening kit Extension cable shortening kit for cable between housing adapter and mounting bracket:
• Order number: 935666-0020
Suspension clamp Suspension clamp for Deltapilot S DB53:
• Material: stainless steel AISI 316L (1.4435), clamping jaw: fiberglass reinforced PA (polyamide)
• Order number: 52010869
→ See also Page 30, "Dimensions of Deltapilot S DB53 and DB53(A) "Suspension clamp and mounting bracket"
section.
For aluminum housing For polyester housing For stainless steel
housing
Material EN AC-44200 with
synthetic coating, gray,
sight glass: glass
Cover (transparent):
polycarbonate (PC)
AISI 316L (1.4404),
sight glass: glass
Order number 942828-0010 942828-0001 942828-0100
Order code Version
HDB50-A 5 m PE cable with mounting bracket AISI 304 (1.4301)
HDB50-B … m PE cable (1 to 30 m) with mounting bracket AISI 304 (1.4301)
HDB50-C 5 m FEP cable with mounting bracket AISI 304 (1.4301)
HDB50-D … m FEP cable (1 to 30 m) with mounting bracket AISI 304 (1.4301)
