Deltapilot S
Endress+Hauser 57
Protective cover
P01-DB5xxxxx-00-xx-xx-xx-001
Protection cover
For the aluminum and polyester housing, Endress+Hauser offers protective covers with two cable entries.
• Max. ambient temperature: +70°C (+158°F)
• Material: polyamide (PA)
• Order number for protection cover for devices with a flat cover: 942262-0000
• Order number for protection cover for devices with a high cover: 942262-0001
Welding flanges
P01-DB5xxxxx-06-xx-xx-xx-032
Welding flange for flush-mounted installation for devices with a DRD flange.
Note!
• Order number for a replacement PTFE flat seal: 916783-0000
110
137
155
ø125
ø50
ø66
ø105
45°
3
13
16
15
20
4xM10
4 x 90° (= 360°)
ø84
Version Order number
DRD DN 50, AISI 316L (1.4435) 52002041
DRD DN 50, 3.1, AISI 304 (1.4301) 52011899
DRD DN 50, AISI 304 (1.4301) 916743-0000
