Deltapilot S
38 Endress+Hauser
DB50L – compact version for
hygienic applications
→For continuation of ordering information for DB50L, see the following page.
10 Approval:
A Version for non-hazardous area
E Version for non-hazardous area, overfill protection WHG
G ATEX II 1/2 G EEx ia IIC T6
D ATEX II 1/2 G EEx ia IIC T6, overfill protection WHG
N ATEX II 3 G EEx nA II T6
S CSA IS, Class I, Division 1, Groups A – D
T CSA IS, Class I, Division 2, Groups A – D
20 Probe:
B Compact version + inspection certificate as per EN 10204–3.1 material (AISI 316L wetted)
C Compact version
Only in conjunction with an approved
process connection
30 Process connection:
Tri-Clamp connections
50 ISO 2852 DN 40 – 51 (2"), DIN 32676 DN 50, AISI 316L, EHEDG, 3A
Hygienic connections
53 SMS 2" PN 25, AISI 316L, EHEDG, 3A
56 IDF 2" ISO 2853, AISI 316L, EHEDG, 3A
55 Varivent type N for pipes DN 40 – DN 162, PN 40, AISI 316L, EHEDG
44 DRD 65 mm, PN 25, AISI 316L, EHEDG, 3A
00 Universal process adapter 44 mm incl. silicone molded seal, 3A
57 Universal process adapter 44 mm, extension 6" incl. silicone molded seal, 3A
40 DIN 11851 DN 40 PN 40, AISI 316L
41 DIN 11851 DN 50 PN 40, AISI 316L
74-02
®
40 Measuring range:
BA 0 to 100 mbar/1 mH
2
O/40 inH
2
O
BB 0 to 400 mbar/4 mH
2
O/160 inH
2
O
BC 0 to 1200 mbar/12 mH
2
O/480 inH
2
O
BD 0 to 4000 mbar/40 mH
2
O/1600 inH
2
O
BE 0 to 10 bar/100 mH
2
O/4000 inH
2
O
DA –100 to 100 mbar/1 mH
2
O/40 inH
2
O
DB –400 to 400 mbar/4 mH
2
O/160 inH
2
O
DC –900 to 1200 mbar/12 mH
2
O/480 inH
2
O
DD –900 to 4000 mbar/40 mH
2
O/1600 inH
2
O
DE –0.9 to 10 bar/100 mH
2
O/4000 inH
2
O
50 Linearity; Fill fluid:
1 < 0.2 % of measuring range; FDA compliant
3 < 0.1 % of measuring range; FDA compliant
60 Measuring sensor seal:
5Kalrez
4 Viton (only with universal process adapter)
3 Sensor welded
DB50L Order code
