Deltapilot S
26 Endress+Hauser
Hygienic connections
P01-DB5xxxxx-06-xx-xx-xx-016
Hygienic connections DB50L: DIN 11851 with coupling nut, material: AISI 316L/1.4435, surface roughness of surfaces
in contact with the medium R
a
≤ 0.8 μm as standard. Lower surface roughness on request.
1 Version 53: SMS 2" PN 25, EHEDG, 3A
2 Version 56: ISO 2385 IDF 2", EHEDG, 3A
3 Version 55 : Varivent type N for pipes DN 40 – DN 162 PN 40, EHEDG
4 Version 44: DRD 65 mm PN 25, EHEDG, 3A
5 Version 40: DIN 11851 DN 40 PN 40
6 Version 41: DIN 11851 DN 50 PN 40
Installation height H, devices with universal process adapter, Tri-Clamp or hygienic connection
H
78
ø35.8
10
ø56
Rd 65x1/6
H
92
11
ø68
Rd 78x1/6
ø35.8
4xø11.5
ø65
ø84
H
ø35.8
ø84
ø105
ø35.8
ø68
ø84
H
H
ø35.8
ø77
ø65.3
ø54.2
ø65
ø35.8
H
ø84
Rd 70x1.6"
➀
➂
➁
➃
➄
➅
Cover Aluminum housing
[mm]
Polyester housing
[mm]
Stainless steel
housing [mm]
Without a flame
barrier
Flat 221 221 209
High (with sight glass)
1
1) Devices with the FHB20 display and operating module are always supplied with a high cover or with a cover with a
sight glass.
232 221 225
