EN/DIN, ANSI and JIS flanges
P01-DB5xxxxx-06-xx-xx-xx-029
DB52(A), cable version with flange
1 DB52(A), flange without flame barrier
2 DB52(A), flange with flame barrier
(flame barrier for use in hazardous areas, Zone 0)
3 Clamp for clamping fixture
H For installation height H, see Page 24
LProbe length:
Without approval, EEx nA II T6: 0.5 to 200 m (20 to 7874 inch)
EEx ia IIC T6, FM IS, CSA IS: 0.5 to 100 m (20 to 3937 inch)
→ For process connection dimensions, see Page 23 ff.
➁➀
k
D
f
g
2
55.7
b
H
185
b
HH
➂
g
