Deltapilot S
Endress+Hauser 5
DB50(A), DB51(A), DB52(A) universal usage
• Modular probe program for optimum process adaptation
• DB50(A) compact version: installation in the tank from below or from the side
• DB51(A)/DB52(A) rod and cable extension: installation from above, i.e. easy to equip and retrofit buried
tanks, no additional opening in the tank floor
DB50L/DB50S optimized for the food and pharmaceutical industry
• All typical flush-mounted process connections can be supplied
• Welding flanges
• Stainless steel housing
• All food process connections are gap-free and can be cleaned without any residue left, e.g. CIP cleaning
• USDA/H1 approved transfer liquid as per FDA guidelines
• 3A or EHEDG approvals
P01-DB5xxxxx-12-xx-xx-xx-004
DB53(A) for the water and wastewater industry
• The housing with the electronic insert is mounted outside shafts and tanks in such a way that it is protected
from flooding. The extension cable is secured with a suspension clamp.
• Electronic inserts with an integrated surge arrester provide protection against overvoltage if lightning strikes.
• The stainless steel measuring cell tube (AISI 316L) and the Alloy measuring diaphragm allow use in
aggressive media such as wastewater for example.
• Extension cable up to 200 m in length (up to 100 m in Ex-areas) without strain relief.
• Special measuring cell with gold-rhodium coating for applications in which severe hydrogen formation can
occur (e.g. digested sludge); see also Page 19.
• Special measuring cell with gold-platinum coating for acids, alkalis or sea water; see also Page 19.
74 - 02
®
