Appendix Ecograph T, RSG35
100 Endress+Hauser
Engineering unit
Navigation Expert → Inputs → Universal inputs → Universal input x → Engineering unit
Direct access code: 220004-0xx
Examples: Universal input 1: 220004-000; Universal input 12: 220004-011
Description Specify the technical (physical) unit for the measuring point connected to this input.
Only visible if signal ≠ switched off.
User entry Text (6 characters)
Unit/dimension counter
Navigation Expert → Inputs → Universal inputs → Universal input x → Unit/dimension counter
Direct access code: 220024-00x
Examples: Universal input 1: 220024-000; Universal input 12: 220024-011
Description Technical units of the count input, e.g. gal, cf.
Only visible if signal = "Pulse counter" and plot type = "Current value + counter".
User entry Text (max. 6 characters)
Pulse counter
Navigation Expert → Inputs → Universal inputs → Universal input x → Pulse counter
Direct access code: 220017-0xx
Examples: Universal input 1: 220017-000; Universal input 12: 220017-011
Description Please check if the pulse counter used is a fast or slow (up to a max. 25 Hz) counter. For
example if the number of state changes from a relay are to be monitored then you must
set up "up to 25Hz".
Only visible if signal = pulse counter.
Options Up to 13kHz, Up to 25Hz
Factory setting Up to 13kHz
Pulse value
Navigation Expert → Inputs → Universal inputs → Universal input x → Pulse value
Direct access code: 220010-0xx
Examples: Universal input 1: 220010-000; Universal input 12: 220010-011
