Ecograph T, RSG35 Appendix
Endress+Hauser 99
Factory setting 4-wire
Channel ident.
Navigation Expert → Inputs → Universal inputs → Universal input x → Channel ident.
Direct access code: 220003-0xx
Examples: Universal input 1: 220003-000; Universal input 12: 220003-011
Description Name of the measuring point connected to this input.
Only visible if signal ≠ switched off.
User entry Text (16 characters)
Factory setting Channel x
Plot type
Navigation Expert → Inputs → Universal inputs → Universal input x → Plot type
Direct access code: 220016-0xx
Examples: Universal input 1: 220016-000; Universal input 12: 220016-011
Description The analog inputs are scanned in a 100ms cycle. Depending on the memory cycle, the
selected data are determined, saved, and displayed based on the scanned values.
Options Instantaneous value, Average, Minimum value, Maximum value, Minimum + Maximum,
Counter, Current value + Counter
Factory setting Average
Time base
Navigation Expert → Inputs → Universal inputs → Universal input x → Time base
Direct access code: 220025-0xx
Examples: Universal input 1: 220025-000; Universal input 12: 220025-011
Description A current value can be determined from the counter reading with the aid of the time base
e.g. input liters, time base = second → current value = liters/second.
Only visible if signal = "Pulse counter" and plot type = "Current value + counter".
Options Second (s), Minute (min), Hour (h), Day (d)
Factory setting Second (s)
