Appendix Ecograph T, RSG35
98 Endress+Hauser
Navigation Expert → Inputs → Universal inputs → Universal input x → Signal
Direct access code: 220000-0xx
Examples: Universal input 1: 220000-000; Universal input 12: 220000-011
Description Select the type of signal connected (current, voltage, etc.). The channel is switched off if no
signal type is selected (factory default).
Options Switched off, Current, Voltage, Resistance temperature detector, Thermocouple, Pulse
counter, Frequency input, Modbus Slave (option)
Factory setting Switched off
Range
Navigation Expert → Inputs → Universal inputs → Universal input x → Range
Direct access code: 220001-0xx
Examples: Universal input 1: 220001-000; Universal input 12: 220001-011
Description Select the input range or which resistance thermometer/thermocouple is connected. The
respective terminal layout can be found in the Operating Instructions or on the rear of the
unit.
Only visible if signal ≠ switched off.
Options Switched off
Current: 4-20 mA, 0-20 mA, 0-5 mA, 0-20 mA squared, 4-20 mA squared, ±20 mA
Voltage: 0-1 V, 0-10 V, 0-5 V, 1-5 V, ±150 mV, ±1 V, ±10 V, ±30 V, 0-1 V squared, 0-10
V squared, 1-5 V squared
Resistance thermometer: Pt100 (IEC), Pt100 (JIS), Pt100 (GOST), Pt500 (IEC), Pt500 (JIS),
Pt1000 (IEC), Pt1000 (JIS), Pt46 (GOST), Pt50 (GOST), Cu50 (GOST, a=4260), Cu50
(GOST, a=4280), Cu53 (GOST, a=4280), Cu100 (GOST, a=4280)
Thermocouple: Type A (W5Re-W20Re), type B (Pt30Rh-Pt6Rh), type C (W5Re-W26Re),
type D (W3Re-W25Re), type J (Fe-CuNi), type K (NiCr-Ni), type L (Fe-CuNi), type L (NiCr-
CuNi, GOST), type N (NiCrSi-NiSi), type R (Pt13Rh-Pt), type S (Pt10Rh-Pt), type T (Cu-
CuNi)
Pulse counter
Frequency input
Modbus (option)
Factory setting Switched off
Connection
Navigation Expert → Inputs → Universal inputs → Universal input x → Connection
Direct access code: 220002-0xx
Examples: Universal input 1: 220002-000; Universal input 12: 220002-011
Description Specify whether RTDs are connected as 2-, 3- or 4-wire systems.
Only visible if signal = resistance thermometer.
Options 2-wire, 3-wire, 4-wire
