Appendix Ecograph T, RSG35
114 Endress+Hauser
Factory setting Digital x
Engineering unit
Navigation Expert → Inputs → Digital inputs → Digital input x → Engineering unit
Direct access code: 250002-00x
Examples: Digital input 1: 250002-000; Digital input 6: 250002-005
Description Technical units of the count input, e.g. gal, cf.
Only visible if function = pulse counter or quantity from time.
User entry Text (max. 6 characters)
Decimal point
Navigation Expert → Inputs → Digital inputs → Digital input x → Decimal point
Direct access code: 250004-00x
Examples: Digital input 1: 250004-000; Digital input 6: 250004-005
Description Number of places after decimal point for the display.
Only visible if function = pulse counter or quantity from time.
Options None, One (X.Y), Two (X.YY), Three (X.YYY), Four (X.YYYY), Five (X.YYYYY)
Factory setting One (X.Y)
Input factor in
Navigation Expert → Inputs → Digital inputs → Digital input x → Input factor in
Direct access code: 250019-00x
Examples: Digital input 1: 250019-000; Digital input 6: 250019-005
Description Defines if the set up factor is respective to 1 second or 1 hour.
Only visible if function = quantity from time.
Options Seconds, hours
Factory setting Seconds
Pulse value
