Enertech VS Series - Section 4: Unit Data Information; Dimensional Data and Clearances

11
IOM, VS/VT Models, Rev A Enertech Global
Dimensional Data and Installation Clearances
Section 4: Unit Data Information
DETAIL A
A
B




A
B
C
K
D
M
O
N
E
F
G
J
L
H
Q
1.00
U
T
S
R
Optional Filter Rack
Tonnage Order Item #
006-012 AFR1721A
015-036 AFR2226A
042-072 AFR2430A
Note:
The Return Duct Dimensions
Are The Same For The Unit
And The Filter Rack.
The Filter Rack Causes The
Return Duct To Be Offset From
The Unit By 2.34 inches
See Detail A
Enertech Recommends A Minimum of 2
to 2 1/2 Feet of Service Area Clearance
For Installation And Maintenance.








2.34
Notes:
Right hand return dimensions are mirrored to the opposite side
as the left hand return dimensions.
Commercial units 006-012 Tons have 3/4" FPT source water connections.
Commercial units 015-072 Tons have 1" FPT source water connections
Residential units have 1" Double O-Ring source water connections.
All Desuperheater connections are 3/4" FPT.
All electrical knockouts are sized for 1/2" or 3/4" c
onduit.
All measurements are in inches.
All drawings are typical, individual models will vary.
CONDENSATE
DRAIN
HIGH VOLTAGE
T-STAT
CONNECTION
EXTERNAL
ELECTRIC HEAT
EXTERNAL
PUMP SUPPLY
SOURCE WATER IN
SOURCE WATER OUT
HOT WATER IN
HOT WATER OUT
P




SOURCE WATER IN
P
EXTERNAL
ELECTRIC HEAT
HIGH VOLTAGE
T-STAT
CONNECTION
EXTERNAL
PUMP SUPPLY
HOT WATER IN
HOT WATER OUT
SOURCE WATER OUT
CONDENSATE DRAIN
1.00
Q
H
L
G
F
E
N
O
M
D
K
C
C*
1.00
Close Coupled
Electric Heater
1.00
1.00
REV DESCRIPTION
A ADDED HEATER
B ADDED 009-012 042-072
C ADDED 006
D ADDED PLASTIC PAN
ECN
15-137-N02
15-219-N02
16-048-N13
16-323-N20
DATE APPROVED
4/30/15 M.TRIPP
6/3/15 M.TRIPP
6/20/16 M.TRIPP
11/14/2016 M.TRIPP
20D801-14NN
DIMENSIONAL DATA TABLE
* ** *** * **
A 21.50 22.50 22.50 22.50 25.00 25.00
B 21.50 22.50 22.50 22.50 27.88 27.88
C 30.00 37.25 37.25 37.25 41.00 41.00
C* N/A 4.75 4.75 4.75 6.50 6.50
D 3.10 3.10 13.34 3.10 3.10 12.75
E 14.125 22.10 22.10 22.10 16.63 16.63
F N/A 26.88 26.88 26.88 24.13 24.13
G N/A 29.63 29.63 29.63 26.88 26.88
H 5.375 8.75 8.75 5.38 5.38 5.38
J 19.50 20.00 20.00 20.00 23.00 23.00
K 15.50 25.00 25.00 25.00 29.00 29.00
L 12.67 10.43 10.43 10.43 10.17 10.17
M 5.625 5.13 5.13 5.13 5.13 5.13
N 7.375 6.88 6.88 6.88 6.88 6.88
O 9.375 8.88 8.88 8.88 8.88 8.88
P 11.875 11.38 11.38 11.38 11.38 11.38
Q 8.375 5.38 5.38 N/A N/A N/A
R 12.50 12.50 12.50 12.50 15.98 15.98
S 11.625 11.63 11.63 11.63 15.98 15.98
T
4.94 5.39 5.39 5.39 5.95 5.95
U 1.93 2.88 2.88 2.88 1.12 1.12
006 - 012MODEL SIZE
042 - 072
OVERALL
CABINET
Note: Add C* to C For Units With Close
Coupled Heater
015 - 036
ELECTRICAL
KNOCKOUTS
NOTE:
* UNITS WITHOUT INTERNAL LOOP PUMP
** UNITS WITH INTERNAL LOOP PUMP
*** UNITS WITH COMPOSITE DRAIN PAN
RETURN AIR
DIMENSIONS
WATER
CONNECTIONS
SUPPLY AIR
DIMENSIONS
Note: Dimensions Are The Same For
Units With Close Coupled Heater
