Enertech VS Series - Performance Data Tables

64
Enertech Global IOM, VS/VT Models, Rev A
HE/HR Table, Standard PSC Blower
Section 11: Equipment Start-Up Procedures
30
o
F 50
o
F 70
o
F 90
o
F 50
o
F 70
o
F 90
o
F 110
o
F
0.8 3.7 5.2 6.6 7.8 9.5 9.2 8.8 8.3
1.1 3.9 5.4 6.9 8.1 9.5 9.3 8.8 8.2
1.5 4.1 5.7 7.1 8.4 9.5 9.3 8.8 8.2
1.1 5.5 7.5 9.7 12.0 14.9 14.1 13.4 12.4
1.7 5.9 8.0 10.4 12.8 15.1 14.2 13.5 12.4
2.3 6.1 8.3 10.7 13.2 15.1 14.3 13.5 12.3
1.5 6.1 8.6 11.1 13.6 15.7 15.0 14.1 13.1
2.3 6.6 9.1 11.8 14.3 16.0 15.2 14.2 13.2
3.0 6.7 9.3 12.1 14.7 16.1 15.3 14.3 13.2
1.9 7.7 10.7 13.9 17.3 20.7 19.5 18.6 17.2
2.8 8.1 11.3 14.7 18.2 20.8 19.5 18.6 17.1
3.8 8.5 11.8 15.3 18.9 20.7 19.4 18.4 16.9
2.3 10.2 14.3 18.1 22.3 26.3 25.5 24.7 23.9
3.4 11.0 15.2 19.2 23.6 26.3 25.5 24.5 23.6
4.5 11.3 15.7 19.7 24.2 26.7 25.8 24.8 23.7
3.0 13.6 18.2 23.5 28.5 33.2 32.4 31.2 30.2
4.5 14.3 19.1 24.6 29.8 33.3 32.4 31.0 29.8
6.0 14.9 19.8 25.5 30.9 33.3 32.4 31.0 29.7
3.8 13.7 19.0 24.6 30.3 38.8 37.8 36.2 34.7
5.6 16.7 22.8 29.4 36.0 38.9 37.7 36.0 34.4
7.5 17.6 23.9 30.8 37.7 38.9 37.7 36.0 34.3
4.5 20.1 27.3 35.6 44.0 49.3 48.2 46.6 45.0
7.0 21.4 28.9 37.6 46.4 49.3 48.0 46.2 44.4
9.0 22.1 29.8 38.7 47.8 49.2 47.9 46.0 44.2
5.3 21.6 30.1 39.1 48.5 54.5 53.8 51.7 50.1
7.9 23.1 32.1 41.6 51.5 54.5 53.8 51.5 49.7
10.5 23.7 32.9 42.6 52.8 54.5 53.7 51.3 49.5
6.0 26.0 35.3 45.0 55.3 63.8 63.5 61.6 59.5
9.0 27.7 37.4 47.7 58.5 63.8 63.5 61.3 59.0
12.0 28.7 38.6 49.2 60.3 63.9 63.5 61.3 58.8
7.5 31.3 42.5 53.7 65.1 73.8 73.9 72.0 69.4
11.3 33.2 44.9 56.7 68.7 73.7 73.7 71.5 68.7
15.0 33.9 45.9 58.0 70.1 73.4 73.4 71.2 68.2
9.0 33.1 46.6 60.0 73.5 89.7 89.7 86.4 83.1
13.5 35.1 49.3 63.4 77.5 89.7 89.6 86.0 82.3
18.0 36.2 50.8 65.3 79.7 89.6 89.4 85.7 81.9
VS006 300/300
VS018 600/600
1. Capacity data is based on 15% (by mass) methanol antifreeze solution (multiplier: 485).
2. Heating data is based on 70°F EAT. Cooling data is based on 80/67°F EAT. Any condition outside performance table(s) requires
correction factor(s).
3. Performance data accurate within ±15%.
VS024 800/800
VS030 1000/1000
VS036
VS042 1450/1450
VS048 1550/1550
VS060 1850/1850
Model GPM
CFM
(Heating/Cooling)
Heat of Extraction (MBtuh) Heat of Rejection (MBtuh)
1200/1200
9. Due to variations in installation, actual unit performance may vary from the tabulated data.
6. Performance data is based upon the lower voltage of dual voltage rated units.
7. Interpolation of unit performance data is permissible; extrapolation is not.
8. Performance data is a result of lab testing and is not related to warranty.
5. Capacity data includes fan power but not pump power and it does not reflect fan or pump power correction for AHRI/ISO conditions.
4. Unit performance test is run without hot water generation.
VS072 2100/2100
VS009 350/350
VS012 350/350
VS015 500/500
30
o
F 50
o
F 70
o
F 90
o
F 50
o
F 70
o
F 90
o
F 110
o
F
1.9 7.7 10.9 14.0 17.3 21.2 20.0 19.2 17.8
2.8 8.2 11.5 14.8 18.3 21.4 20.1 19.2 17.6
3.8 8.5 11.9 15.3 18.9 21.4 20.1 19.1 17.5
2.3 10.5 14.6 18.4 22.6 26.9 26.2 25.4 24.6
3.4 11.2 15.5 19.5 24.0 27.0 26.2 25.2 24.3
4.5 11.6 16.0 20.0 24.6 27.4 26.5 25.5 24.4
3.0 13.7 18.2 23.6 28.7 33.1 32.4 31.1 30.1
4.5 14.5 19.1 24.7 30.0 33.2 32.4 31.0 29.8
6.0 15.0 19.7 25.5 30.9 33.4 32.5 31.0 29.7
3.8 16.2 22.1 28.3 34.9 38.6 37.6 36.1 34.6
5.6 17.0 23.1 29.6 36.4 38.8 37.7 36.0 34.3
7.5 17.6 23.9 30.6 37.6 38.9 37.7 35.9 34.2
4.5 20.1 27.3 35.5 43.9 48.7 47.5 45.8 44.2
7.0 21.4 28.9 37.5 46.4 48.6 47.3 45.5 43.6
9.0 22.0 29.7 38.6 47.7 48.6 47.2 45.3 43.4
5.3 21.6 30.1 39.0 48.5 54.5 53.8 51.8 50.2
7.9 23.1 32.0 41.5 51.5 54.5 53.8 51.5 49.7
10.5 23.7 32.8 42.5 52.7 54.5 53.7 51.3 49.5
6.0 26.1 35.2 45.0 55.2 64.0 63.8 62.0 59.9
9.0 27.7 37.4 47.6 58.4 64.1 63.8 61.7 59.3
12.0 28.7 38.6 49.1 60.2 64.2 63.8 61.6 59.1
7.5 31.6 42.8 54.1 65.5 74.7 74.9 73.1 70.6
11.3 33.4 45.2 57.1 69.2 74.6 74.7 72.6 69.8
15.0 34.2 46.3 58.4 70.6 74.4 74.4 72.2 69.3
9.0 33.3 46.9 60.4 73.8 90.5 90.6 87.3 84.2
13.5 35.3 49.5 63.7 77.9 90.5 90.4 86.9 83.3
18.0 36.4 51.0 65.6 80.1 90.5 90.3 86.6 82.9
VS036 1200/1100
Heat of Extraction (MBtuh) Heat of Rejection (MBtuh)
VS024 800/800
VS030 1000/1000
VS018 700/700
Model GPM
CFM
(Heating/Cooling)
VS015 550/550
6. Performance data is based upon the lower voltage of dual voltage rated units.
7. Interpolation of unit performance data is permissible; extrapolation is not.
8. Performance data is a result of lab testing and is not related to warranty.
9. Due to variations in installation, actual unit performance may vary from the tabulated data.
1. Capacity data is based on 15% (by mass) methanol antifreeze solution (multiplier: 485).
2. Heating data is based on 70°F EAT. Cooling data is based on 80/67°F EAT. Any condition outside performance table(s) requires correction factor(s).
3. Performance data accurate within ±15%.
4. Unit performance test is run without hot water generation.
5. Capacity data includes fan power but not pump power and it does not reflect fan or pump power correction for AHRI/ISO conditions.
VS072 2180/2200
VS042 1400/1450
VS048 1540/1610
VS060 1980/2000
HE/HR Table, Optional ECM Blower
VS Series, Heat of Extraction/Heat of Rejection Tables
