Enertech Global IOM, VS/VT Models, Rev A
QR Codes for Installation or Troubleshooting Tip
Videos
Select the topic for your maintenance need. Scan the QR
code to access the video. Follow the directions and tips
provided to make your project easier to complete
ECM Temporary Replacement
ECM Motor Troubleshooting
Troubleshooting a TXV
Compressor Troubleshooting
Variable Speed Flow Centers
Return Conversion for and XT or CT
Heat Of Extraction and Rejection
Measuring Subcooling/Superheat
Nitrogen Purge While Brazing
Leak Testing an Air Coil
Loop Flushing
Repairing a Microchannel Air Coil
Testing a Coaxial Heat Exchanger
Troubleshooting a TXV
Section 12: Troubleshooting
Performance Check
Heat of Extraction(HE)/Rejection(HR)
Record information on the Unit Start-up Form
Equipment should be in full load operation for a
minimum of 10 minutes in either mode – WITH THE
HOT WATER GENERATOR TURNED OFF.
1. Determine ow rate in gallons per minute
• Check entering water temperature
• Check entering water pressure
• Check leaving water pressure
Once this information is recorded,
• Find corresponding entering water temperature
column in the HE/HR Table.
• Find pressure differential in PSI column.
• Then read the GPM column to determine ow in
GPM.
2. Check leaving water temperature of unit.
• FORMULA: GPM x water temp diff. x 485
(antifreeze) or 500 (fresh water) = HE or HR in
BTU/HR
A 10% variance from table is allowed. Always use
the same pressure gauge & temperature measuring
device. Water ow must be in range of table. If
system has too much water ow, performance
problems should be expected.
