Enertech VS Series - Unit Physical Data

13
IOM, VS/VT Models, Rev A Enertech Global
Section 4: Unit Data Information
Unit Physical Data
*Always check the unit data plate for charge volume
Unit Physical Data
Model Number
006 009 012 015 018 024 030 036 042 048 060 072 024 036 048 060 072
Compressor Type
Fan Wheel (in.)
9 x 7 10 x 8 9 x 7 10 x 8
Fan Motor PSC (HP)
1/4 1/4 1/3 1/3 1/2 1/2 3/4 1 1 N/A N/A N/A N/A N/A
Fan Motor ECM (HP)
N/A N/A N/A 1/2 1/2 1/2 1/2 1/2 3/4 3/4 1 1 1/2 1/2 3/4 1 1
Refrigerant Charge
(oz.)
29 30 28.5 41 43 45 53 54 69 69 65 70 45 54 69 69 64
Face Area (Sq. Ft.)
Dimensions (in.)
Number of Rows
Shipped Unit Weight
(Nominal) lbs.
187 187
187
234
240 248 265 271 357 360 375 367 248 271 361 373 375
N/A Micro-Channel Coil
25.4 x 19.8 x 1 28.9 x 23.7 x 1.26
Single Stage Scroll
6 x 8
1/10
Single Stage Rotary
15.5 x 18.8 x 1
11 x 10
25.4 x 19.8 x 1
11 x 10
Dual Stage Unloading Scroll
VS/VT Vertical Packaged Unit
Air Coil
4.76
28.9 x 23.7 x 1.26
4.763.492.02
9 x 7
3.49
