LED Identication
Section 9: Controls
Fault
Code
Condition
leds
notes
Green
HP
Orange
LP
Red
Fs
Yellow
Co
GReen
status
l
teRminal
01 Normal mode - - - - Flash -
02
TesT mode - - - - - - 1
03
high Pressure FaulT (hP) Flash - - - Flash -
04
high Pressure lockouT (hP) oN - - - Flash oN
05 low Pressure FaulT (lP) - Flash - - Flash -
06
low Pressure lockouT (lP) - oN - - Flash oN
07 source heaT exchaNger
Freeze/waTer Flow FaulT (T4/
Fs)
- - Flash - Flash - 2
08
source heaT exchaNger
Freeze/waTer Flow lockouT
(T4/Fs)
- - oN - Flash oN 2
09
load heaT exchaNger Freeze
FaulT (T1)
- Flash Flash - Flash - 3,4
10
load heaT exchaNger Freeze
lockouT (T1)
- oN oN - Flash oN 3,4
11
coNdeNsaTe FaulT (co) - - - Flash Flash -
12
coNdeNsaTe lockouT (co) - - - oN Flash oN
13 over/uNder volTage Flash Flash Flash Flash Flash oN
14 seNsor T1 Bad lockouT Flash - - oN Flash Flash 5
15
seNsor T2 Bad - Flash - oN Flash Flash 5, 8
16
seNsor T3 Bad - - Flash oN Flash Flash 5, 8
17
seNsor T4 Bad lockouT - oN - Flash Flash Flash 5
18
T1 & T4 swaPPed oN - - oN - Flash 6
19
hgT(T2) > 220F FaulT Flash - Flash oN Flash - 7
20
hgT(T2) > 220F lockouT oN - oN oN Flash oN 7
Notes:
1. When the TEST jumper is removed, the green status LED will be off.
2. The source heat exchanger freeze/water ow fault sensor is located between the TXV and source heat exchanger.
3. The load heat exchanger freeze sensor is located between the TXV and the load heat exchanger.
4. Only package and Water-to-Water models have this feature.
5. This fault indicates a bad sensor - open, shorted, disconnected, or invalid value.
6. Check for T1 & T4 being swapped (only shown in TEST mode).
7. Hot Gas Line temperature is too high (>220F).
8. Units without HWG do not use sensors T2 and T3. The control will disable faults 15 and 16.
