Enertech VS Series - Typical Unit Piping Connections; External Flush Valves

24
Enertech Global IOM, VS/VT Models, Rev A
Typical Unit Piping Connections
~~
Flush
Valves
Hose
Kit
To/From
Loop Field
SOURCE WATER IN
SOURCE WATER OUT
HOT WATER OUT
HOT WATER IN
CONDENSATE DRAIN
Equipment Pad
2” Polyethylene Foam
Notes: P/T ports should be angled away from the
unit for ease of gauge reading.
Drawings represent typical installation. The
manufactures installation guides should be used
for nal installation
Section 5: Unit Piping Installation
~
~
Flow
Center
Hose
Kit
To/From
Loop Field
SOURCE WATER IN
SOURCE WATER OUT
HOT WATER OUT
HOT WATER IN
CONDENSATE DRAIN
Equipment Pad
2” Polyethylene Foam
~ ~
Flow
Center
Hose
Kit
To/From
Loop Field
SOURCE WATER IN
SOURCE WATER OUT
HOT WATER OUT
HOT WATER IN
CONDENSATE DRAIN
Equipment Pad
2” Polyethylene Foam
Pressurized Flow Center
Non-Pressurized Flow Center
External Flush Valves
