Enertech VS Series - VT Series, Heat of Extraction;Heat of Rejection Tables; HE;HR Table, Standard ECM Blower

65
IOM, VS/VT Models, Rev A Enertech Global
HE/HR Table, Standard ECM Blower
Section 11: Equipment Start-Up Procedures
30
o
F 50
o
F 70
o
F 90
o
F 50
o
F 70
o
F 90
o
F 110
o
F
2.0 8.8 12.6 16.4 20.2 23.9 23.2 22.6 21.8
3.0 9.4 13.3 17.4 21.3 23.9 23.1 22.4 21.4
4.0 9.8 13.8 17.9 21.9 24.0 23.2 22.3 21.3
3.0 13.5 18.1 23.3 28.4 33.5 32.4 31.2 30.1
4.5 14.2 19.1 24.5 29.9 33.5 32.3 31.1 29.8
6.0 14.6 19.6 25.1 30.6 33.7 32.5 31.2 29.9
3.0 12.8 18.2 23.9 29.4 34.0 33.3 32.4 31.5
4.5 13.8 19.4 25.4 31.2 34.2 33.3 32.1 31.0
6.0 14.4 20.2 26.4 32.4 34.2 33.3 32.0 30.8
4.5 19.5 27.0 34.3 41.8 48.3 47.1 45.8 44.1
7.0 20.9 28.8 36.4 44.3 48.3 46.9 45.5 43.6
9.0 21.6 29.7 37.6 45.7 48.2 46.8 45.3 43.4
4.0 16.7 23.9 32.4 41.6 44.8 44.8 42.4 40.2
6.0 18.0 25.5 34.4 44.2 45.1 44.9 42.2 39.6
8.0 18.6 26.4 35.5 45.5 45.1 44.7 41.8 39.0
6.0 26.0 35.1 45.0 53.8 62.8 64.3 62.4 59.9
9.0 27.4 36.9 47.2 56.5 62.7 64.1 62.0 59.2
12.0 28.2 38.0 48.5 58.1 62.7 64.0 61.8 58.9
5.0 21.8 30.5 40.3 49.9 54.6 55.5 53.8 51.5
7.5 23.4 32.6 43.0 53.1 54.9 55.6 53.6 50.9
10.0 24.3 33.8 44.5 54.9 54.9 55.5 53.2 50.3
7.5 31.7 42.5 54.8 67.4 76.3 78.4 76.5 73.3
11.3 33.6 45.0 57.9 71.1 76.4 78.4 76.2 72.8
15.0 34.6 46.3 59.5 73.2 76.7 78.7 76.4 72.8
6.0 24.1 34.7 46.0 57.3 64.9 65.2 62.4 59.9
9.0 26.0 37.2 49.1 61.1 65.4 65.5 62.2 59.2
12.0 27.0 38.5 50.8 63.2 65.5 65.3 61.9 58.5
9.0 34.5 47.4 61.1 72.4 85.6 88.1 86.1 82.8
13.5 36.4 50.0 64.2 76.1 85.6 88.0 85.7 82.0
18.0 37.5 51.4 66.1 78.2 85.6 87.9 85.6 81.7
8. Performance data is a result of lab testing and is not related to warranty.
9. Due to variations in installation, actual unit performance may vary from the tabulated data.
800/800
1200/1100
Heat of Extraction (MBtuh) Heat of Rejection (MBtuh)
VT024
Part Load
Full Load
CFM
(Heating/Cooling)
500/500
800/800
VT036
Part Load
Full Load
Model GPM
1. Capacity data is based on 15% (by mass) methanol antifreeze solution (multiplier: 485).
2. Heating data is based on 70°F EAT. Cooling data is based on 80/67°F EAT. Any condition outside performance table(s) requires correction
factor(s).
3. Performance data accurate within ±15%.
4. Unit performance test is run without hot water generation.
Full Load 2180/2200
5. Capacity data includes fan power but not pump power and it does not reflect fan or pump power correction for AHRI/ISO conditions.
6. Performance data is based upon the lower voltage of dual voltage rated units.
7. Interpolation of unit performance data is permissible; extrapolation is not.
VT048
Part Load 1250/1270
Full Load 1540/1610
VT060
Part Load 1680/1580
Full Load 1980/2000
VT072
Part Load 1850/1800
VT Series, Heat of Extraction/Heat of Rejection Tables
