Enertech VS Series - Equipment Start-Up Form

63
IOM, VS/VT Models, Rev A Enertech Global
EQUIPMENT START-UP FORM
Customer Name:_________________________________________________________________
Customer Address:_____________________________________________________________________________________
Model #:__________________________________________ Serial #:____________________________________________
Dealer Name:__________________________________________________________________________________________
Distributor Name:_____________________________________________ Start-up Date:____________________________
Installer/Technician:____________________________________________ Date:________________________
enil siht gnola tuC
Unit Electrical Data
PSI PSI V
PSI PSI A A
PSI PSI A A
GPM GPM GA
A
Loop Type: Open Closed
(Circle One)
Line Voltage
Wire Size
Circuit Breaker Size
Cooling
Heating
Cooling
Heating
Flow Rate
*Check pressure drop chart for GPM
Total Unit Amps
Compressor Amps
Flow Rate
Source Water Pressure In
Source Water Pressure Out
Source Water Pressure Drop
ºF ºF
ºF ºF
ºF ºF
Heat of Rejection/Extraction
BTU/HR
BTU/HR
ºF ºF
ºF ºF
ºF ºF
Cooling Heating
ºF ºF
ºF ºF
ºF ºF
Heating
ºF
ºF
ºF
Heating
V
A
GA
A
Source Water Temp. Difference
Cooling
Heating
Source Water Temperature In
Source Water Temperature Out
Source Water Temperature Difference
Cooling
Heating
Load Water Temp. Difference
Cooling
Heating
Heat of Extraction/Rejection = GPM X Water Temp. Difference X 485 (Water & Antifreeze - Closed Loop)
Heat of Rejection
Heat Of Extraction
Load Water Temperature In
Load Water Temperature Out
Load Water Temperature Difference
Heat of Extraction/Rejection = GPM X Water Temp. Difference X 500 (Water - Open Loop)
Air Temperature Difference
Supply Air Temperature
Return Air Temperature
Air Temp. Difference
Auxiliary Heat Operation Only
Supply Air Temperature
*Confirm auxiliary heaters are de-energized for the above readings.
Return Air Temperature
Air Temp. Difference
Auxiliary Heat Electrical Data
CFM = (Watts X 3.413) ÷ (Air Temp. Difference X 1.08)
Watts = Volts X Auxiliary Heater Amps
Line Voltage
Total Amperage (Full kW - All Stages)
Wire Size
Breaker Size
Section 11: Equipment Start-Up Procedures
Equipment Start-Up Form
