Enertech VS Series - Desuperheater Fitting Kit and Configurations

34
Enertech Global IOM, VS/VT Models, Rev A
Section 6: Desuperheater Installation
⚠ WARNING ⚠
To avoid serious injury, it is recommended that
an anti-scald mixing valve is installed on the hot
water supply line into the home. Even though hot
water hot water tank temperatures could appear
to be set at lower levels, high temperature
water from the desuperhater could raise tank
temperatures.
Contents of the Desuperheater Fitting Kit
• (1) p/n 20D052-01NN, Installation Instructions
• (1) p/n 33P211-01BN, 3/4”x 3/4”x 3/4” FPT Brass
Tee
• (1) p/n 33P210-01NN, ¾” Boiler Drain Valve
• (1) p/n 11080005001, ¾” MPT x 3-1/2” Brass
Nipple
• (3) p/n 11080006001, ½” SWT x ¾” MPT Copper
Adaptor
• (1) p/n 11080007001, ¾” x ¾” x ½” SWT Copper
Tee
Water Heater Connection Kit Assembly for Bottom of
Water Heater
Note: Drawing shown vertically for detail. Fitting
installs horizontally into hot water tank.
Connection to Hot
Water Tank
Brass Tee
Adapter to Unit
Water Line
Drain
Copper Tee
For Domestic
Cold Water In
Line
