11b/g Wireless Long Range Multi-function 7+1 AP Version 1.1
109
Appendix A – Specifications
Hardware Spécifications
Physical Interface z LAN: One 10/100 Fast Ethernet RJ-45
z Reset Button
z Power Jack
LEDs Status z Power/ Status
z Internet (WAN)
z WLAN (Wireless Connection)
z LAN (10/100Mbps)
Power Requirements
z Power Supply: 90 to 240 VDC ± 10％, 50/60 Hz (depends on
different countries)
z Device: 12V/1A
Regulation Certifications z FCC Part 15, Class B
z R&TTE Directive 1999/5/EC
z EN 300 328
z EN 301 489
z EN 60950
RF Spécifications
Frequency Band
2.400～2.484 GHz
Media Access Protocol
Carrier sense multiple access with collision avoidance (CSMA/CA)
Modulation Technology
z DSSS / BPSK / QPSK / CCK
/ OFDM
Operating Channels 11 for North America, 13 for Japan, 13 for Europe
Receive Sensitivity
(Typical)
z IEEE802.11g
6/9/12/18Mbps@ -97dB ~ -89dB
24/36Mbps@ -80dB
54Mbps@ -74dB
z IEEE802.11b
1/2/5.5/11Mbps@-97dB ~ -89dB
Available transmit power
z IEEE802.11g
26dBm@6/9/12/18 Mbps
24/36dBm@24/36 Mbps
22dBm@54 Mbps
z IEEE802.11b
Up to 28dBm@1 ~ 11Mbps
Antenna *2
Detachable omni antenna
Peak Gain = 5 dBi
