EnGenius ECB3500 User Manual

11b/g Wireless Long Range Multi-function 7+1 AP Version 1.1
7
1 Introduction
ECB3500 is a powerful, enhanced, enterprise level product that supports 7 multi-
functions to operate for every kind of working environment.
This is a Wireless high transmit output power and high data rate indoor device which
plays different roles of Access Point/ Client Bridge / Repeater / WDS AP / WDSBridge /
Client Router / AP Router. It operates seamlessly in the 2.4 GHz frequency spectrum
supporting the 802.11b (2.4GHz, 11Mbps) and super high speed of 802.11g (2.4GHz,
108Mbps) wireless standards. It supports high output power level settings, bandwidth
selection, RSSI indicator and antenna diversity which enable the best transmitting and
receiving signal for traffic communication.
For more sensitive security requirements, ECB3500 can encrypt all wireless
transmissions through WEP data encryption and WPA/WPA2. ECB3500 also supports
IEEE 802.1x Supplicant function in CB mode, and authenticator in AP mode. Those are
the enhanced security features in AP/CB mode. The MAC address filter lets you select
any stations that should have access to your network. The User isolation function can
protect the private network between client users. Normally, ECB3500 offers mighty
security function for your network safety.
The attractive design, high performance, and array of features make ECB3500 a suitable
wireless solution for your residence or office.
This chapter describes the features, package contents, applications, and network
configuration.
1.1 Features & Benefits
Features Benefits
Super G solution up to 108Mbps Capable of handling heavy data payloads such as
MPEG, video streaming, large file transfer and
VoIP
High Output Power up to 28 dBm
Extended excellent Range and Coverage (fewer
APs)
IEEE 802.11b/g Compliant Fully Interoperable with IEEE
802.11b/IEEE802.11g compliant devices
7+1 Multi Functions Access Point/Client Bridge/Repeater/WDS AP/
WDS Bridge/Client Router/AP Router
Point-to-multipoint Wireless
connectivity
Let users transfer data between two buildings or
multiple buildings
WDS (Wireless Distributed
System)
Make wireless AP and Bridge mode
simultaneously as a wireless repeater
Universal Repeater The easiest way to expand your wireless
networking coverage
Support Multi-SSID function (4
BSSID) in AP mode
Allow clients to access different networks through
a single access point and assign different policies
and functions for each SSID by manager

EnGenius ECB3500 Specifications

General

Modulation	16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, QPSK
Frequency band	2.4 GHz
Channels quantity	13 channels
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	108 Mbit/s
Wireless technology	802.11 b/g
Antenna features	Detachable antenna
Antennas quantity	2
Antenna connector type	TNC
Antenna gain level (max)	5 dBi
Internal	No
Certification	FCC, CE
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 152-bit WEP, 64-bit WEP, 802.1x RADIUS, SSID, WPA, WPA-AES, WPA-PSK, WPA-TKIP
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	-20 - 70 %
Operating relative humidity (H-H)	5 - 95 %
Flash memory	4 MB
Internal memory	32 MB
Input current	1 A
AC input voltage	12 V

Weight and Dimensions

Dimensions (WxDxH)	120 x 120 x 50 mm
