EnGenius ECB3500 User Manual

11b/g Wireless Long Range Multi-function 7+1 AP Version 1.1
8
Antenna diversity support Enhance the traffic signal
WPA2/WPA/ IEEE 802.1x support Powerful data security
802.1x Supplicant support (CB
mode)
More sensitive data security in Client Bridge mode
MAC address filtering in AP
mode(up to 50)
Ensure the security of network connections
User isolation support (AP mode) Protect the private network between client users.
PPPoE function support (CR
mode)
Easy to access internet via ISP service
authentication
Power-over-Ethernet
(IEEE802.3af)
Power supply via Ethernet cable which makes the
setup more flexible avoids restricting from wiring
lines.
1.2 Package Contents
Open the package carefully, and make sure that none of the items listed below are
missing. Do not discard the packing materials, in case of return; the unit must be shipped
in its original package.
h 1* Wireless High power multi-function 7+1 AP (ECB3500)
h 1* 12V/1A Power Adapter
h 1* CAT5 UTP Cable
h 1* QIG
h 1* CD (User’s Manual)
h 2* 5dBi 2.4GHz Dipole Antennas
1.3 Safety Guidelines
In order to reduce the risk of fire, electric shock and injury, please adhere to the following
safety guidelines.
h Carefully follow the instructions in this manual; also follow all instruction labels
on this device.
h Except for the power adapter supplied, this device should not be connected to
any other adapters.
h Do not spill liquid of any kind on this device.
h Do not place the unit on an unstable stand or table. This unit may drop and
become damaged.
h Do not expose this unit to direct sunlight.
h Do not place any hot devices close to this unit, as they may degrade or cause
damage to the unit.
h Do not place any heavy objects on top of this unit.
h Do not use liquid cleaners or aerosol cleaners. Use a soft dry cloth for cleaning.

EnGenius ECB3500 Specifications

General

Modulation	16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, QPSK
Frequency band	2.4 GHz
Channels quantity	13 channels
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	108 Mbit/s
Wireless technology	802.11 b/g
Antenna features	Detachable antenna
Antennas quantity	2
Antenna connector type	TNC
Antenna gain level (max)	5 dBi
Internal	No
Certification	FCC, CE
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 152-bit WEP, 64-bit WEP, 802.1x RADIUS, SSID, WPA, WPA-AES, WPA-PSK, WPA-TKIP
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	-20 - 70 %
Operating relative humidity (H-H)	5 - 95 %
Flash memory	4 MB
Internal memory	32 MB
Input current	1 A
AC input voltage	12 V

Weight and Dimensions

Dimensions (WxDxH)	120 x 120 x 50 mm
