12
GB
142°C
KTY 10/5
KTY 10/5
X4
P+
TEMP.-SENSOR
Nr. 2
Nr. 1
TEMP.-
LIMITER
H-SENSOR
Ub
E G
Sensor connection
P max. 9 kW
X3
X2X1
L1 L2 L3 N
N
N
U
V
W
WB
S1
FAN
LIGHT
WM
L N L N
400 V 3 N AC 50 Hz
max. 100 W
max. 100 W
Connection of sauna heaters ≤ 9 kW
