Technical Manual &
Cabling Instructions
Page 46 / MAN000596
Approvals and Safety
Epec Oy reserves all rights for improvements without prior notice
Epec Oy
Tiedekatu 6
FIN-60320 Seinäjoki
Postal address
PL/P.O.Box 194
FIN-60101 Seinäjoki,
Finland
Phone
+358-(0)20-7608 111
Fax
+358-(0)20-7608 110
Internet
www.epec.fi
Immunity of ESAs to
electromagnetic radiation
• Test method E/ECE Reg. No. 10, Annex 9, ISO
11452-2
• Performance criterion: A
Specification
time
(MHz)
level
Modulation
AM80% 1
kHz
5%
3 s 20-80 60 mA
Modulation
AM80% 1
kHz
2%
3 s 80-1000
30
V/m
PM
577/4600 μs
1%
3 s 800-1000
30
V/m
PM
577/4600 μs
1%
3 s 1000-2000
30
V/m
Classification of functional status
Class A:
All functions of a device/system perform as designed during and after exposure to
disturbance.
Class B:
All functions of a device/system perform as designed during and after exposure to
disturbance. However, one or more of them can go beyond specified tolerance. All functions
return automatically to within normal limits after exposure is removed. Memory functions shall
remain class A.
Class C:
One or more functions of a device/system do not perform as designed during exposure but
return automatically to normal operation after exposure is removed.
Class D:
One or more functions of a device/system do not perfor
m as designed during exposure and do
not return to normal operation until exposure is removed and a device/system is reset by
simple “operator/use” action.
Class E:
One or more functions of a device/system do not perform as designed during exposure and
cannot be returned to operation without repairing the device/system.
