Epson EB-S04 User Manual

101
Image Quality Settings - Image Menu
Settings on the Image menu let you adjust the quality of your image for the
Setting Options Description
input source you are currently using. The available settings depend on the
Color Temp. Color Temp. Sets the color tone based on color
currently selected input source.
temperature. The image is tinted blue
Customized
when a high value is selected and tinted
red when a low value is selected.
Color Temp.: select to set the color
temperature range from 3200K to
10000K (for sRGB mode) or from 0 to 10
(for other color modes).
Customized: adjusts the individual R
(red), G (green), and B (blue)
components of the offset and gain.
Image Noise Reduction Reduces flickering in analog images.
Enhancement
Advanced Deinterlacing Sets whether or not to convert
interlaced-to-progressive signals for
(For interlaced
certain video image types.
signal
[480i/576i/1080i] Off: for fast-moving video images.
input)
Video: for most video images.
To change settings for an input source, make sure the source is connected and
Film/Auto: for movies, computer
select that source.
graphics, and animation.
Auto Iris Off Adjusts the projected luminance based
Setting Options Description
on the image brightness when the Color
Normal
Mode is set to Dynamic or Cinema.
Color Mode See the list of Adjusts the vividness of image colors for
High Speed
available Color various image types and environments.
Reset — Resets all adjustment values except Color
Modes
Mode on the Image menu to their
Brightness Varying levels Lightens or darkens the overall image.
default settings.
available
Contrast Varying levels Adjusts the difference between light and
available dark areas of the image.
• The Brightness setting does not affect lamp brightness. To change
the lamp brightness mode, use the Power Consumption setting in
a
Color Saturation Varying levels Adjusts the intensity of the image colors.
the projector's ECO menu.
available
• You cannot select the Noise Reduction setting when the following
Tint Varying levels Adjusts the balance of green to magenta
are being input.
available tones in the image.
• The Deinterlacing setting is set to Off.
Sharpness Varying levels Adjusts the sharpness or softness of
• A digital RGB signal is being input.
available image details.
• An interlaced signal (480i/576i/1080i) is being input.

Epson EB-S04 Specifications

General

Native aspect ratio	-
Projection distance	1.77 - 2.4 m
Projection technology	3LCD
Contrast ratio (typical)	15000:1
Projection distance (wide)	0.88 - 10.44 m
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	-30 - 30 °
Keystone correction, horizontal	- 30 - 30 °
Projector brightness (economic mode)	2100 ANSI lumens
Focus	Manual
Throw ratio	1.45 - 1.96:1
Digital zoom	1.35 x
Lamp type	UHE
Lamp power	200 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	10000 h
RMS rated power	1 W
Number of built-in speakers	1
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Built-in display	No
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.26 W
Power consumption (typical)	277 W
Power consumption (economy mode)	207 W
Ethernet LAN (RJ-45) ports	0
Cables included	AC, VGA
Remote control type	IR
Operating altitude	0 - 3000 m
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
USB connector type	USB Type-A, USB Type-B
HDMI connector type	Full-size
USB 2.0 ports quantity	2
Pallet width	800 mm
Pallet height	1190 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Quantity per pallet layer	6 pc(s)

Weight and Dimensions

Depth	234 mm
Width	297 mm
Height	77 mm
Weight	2400 g
Package depth	360 mm
Package width	350 mm
Package height	160 mm
Package weight	3829 g
