Epson EB-S04 User Manual

87
Using a QR Code to Connect a Mobile Device
the projector.
After selecting the wireless network settings for your projector, you can
d
Select the Basic menu and press [Enter].
display a QR code on the screen and use it to connect a mobile device using
the Epson iProjection app.
• Make sure you have installed the latest version of Epson iProjection
(V1.3.0 or later) on your device.
a
• You can download Epson iProjection for free from the App Store or
from Google play. Any fees incurred when communicating with the
App Store or Google play are the responsibility of the customer.
• You need to setup a Wi-Fi profile when using Epson iProjection for
iOS for the first time.
a
Press the [Menu] button on the control panel or remote control.
b
Select the Network menu and press [Enter].
e
Set the Display LAN Info. setting to Text & QR Code.
f
Select Complete and then follow the on-screen instructions to save
your settings and exit the menus.
g
Press the [LAN] button on the remote control or select Display the QR
Code in the projector's Network menu.
The QR code is displayed on the projected surface.
If you do not see the QR code after pressing the [LAN] button,
press [Enter] to display the code.
a
h
Start Epson iProjection on your mobile device.
c
Select Network Configuration and press [Enter].
i
Read the projected QR code with your mobile device to connect it to

Epson EB-S04 Specifications

General

Native aspect ratio	-
Projection distance	1.77 - 2.4 m
Projection technology	3LCD
Contrast ratio (typical)	15000:1
Projection distance (wide)	0.88 - 10.44 m
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	-30 - 30 °
Keystone correction, horizontal	- 30 - 30 °
Projector brightness (economic mode)	2100 ANSI lumens
Focus	Manual
Throw ratio	1.45 - 1.96:1
Digital zoom	1.35 x
Lamp type	UHE
Lamp power	200 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	10000 h
RMS rated power	1 W
Number of built-in speakers	1
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Built-in display	No
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.26 W
Power consumption (typical)	277 W
Power consumption (economy mode)	207 W
Ethernet LAN (RJ-45) ports	0
Cables included	AC, VGA
Remote control type	IR
Operating altitude	0 - 3000 m
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
USB connector type	USB Type-A, USB Type-B
HDMI connector type	Full-size
USB 2.0 ports quantity	2
Pallet width	800 mm
Pallet height	1190 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Quantity per pallet layer	6 pc(s)

Weight and Dimensions

Depth	234 mm
Width	297 mm
Height	77 mm
Weight	2400 g
Package depth	360 mm
Package width	350 mm
Package height	160 mm
Package weight	3829 g
